A26361-D1562-Z121-1-6319 English - 31
Annex
Electrical Properties
Loadability for connections and fuses
i
Make sure that the connected devices do not overload the connections.
Valid for Mainboard variant A
Fuse no. Fuse Connection Maximum loadability
- - Fan1, Fan2 1000 mA each
1 750 mA Keyboard Not specified
Mouse Not specified
VGA port Minimum 50 mA
2 1500 mA USB port A 500 mA
USB port B 500 mA
3 1500 mA USB port C 500 mA
USB port D 500 mA
4 1500 mA USB port E 500 mA
USB port F 500 mA
5 1500 mA USB port G 500 mA
USB port H 500 mA
Valid for Mainboard variant C
Fuse no. Fuse Connection Maximum loadability
- - Fan1, Fan2 1000 mA each
1 1500 mA Keyboard Not specified
Mouse Not specified
VGA port Minimum 50 mA
USB port A 500 mA
USB port B 500 mA
2 1500 mA USB port C 500 mA
USB port D 500 mA
3 2000 mA USB port E 500 mA
USB port F 500 mA
USB port G 500 mA
USB port H 500 mA
The fuses on this mainboard can be used several times (polyfuses). Shortly after the error state has
been eliminated, the fuses reset to the original state.
