Board Installation
LCD Header (LCD)







Signal Pin Pin Signal
n.c.
1 2
GND
n.c.
3 4
GND
Key
5 6
RFU
LAN Action
7 8
LAN Link
HD aktiv
9 10
Alert
Message
11 12
Sleep
Power
13 14
VDD
Front USB with Chipcardreader support (FRNT USB - black)






Signal Pin Pin Signal
Key
1 2
CCR on
Power 3 4 Power
USB4- 5 6 USB5-
USB4+ 7 8 USB5+
GND 9 10 GND
Key
11 12
n. c.
HDA compliant Front Panel Audio Header (AUDIO - yellow)





Signal Pin Pin Signal
PORT1-L
1 2
Analog GND
PORT1-R 3 4 Presence Detect
PORT2-R 5 6 PORT1 Sens Return
Jack Sens Send 7 8
Key
PORT2-L 9 10 PORT2 Sens Return
IEEE 1394 Header (FRNT1394 – grey)





Signal Pin Pin Signal
TPA+
1 2
TPA-
GND 3 4 GND
TPB+ 5 6 TPB-
P12VP 7 8 P12VP
Key 9 10 GND
A26361-D1808-Z120-1-7619, edition 1 11
