Upgrading AGP screen controllers
A26361-D1961-Z120-1-7419, edition 2 English - 21
Removing a memory module
1
1
► Push the clips on the right and left of the memory slot outward (1).
► Pull the memory module out of the memory slot (2).
Upgrading AGP screen controllers
Technical data
The AGP slot supports the modes 4x/8x with 32 bits and 66 MHz. Only 1.5 V AGP graphics cards
are supported.
i
Some older 3.3 V AGP graphics cards are coded like 1.5 V AGP graphics cards. The
installation of such 3.3 V AGP graphics cards can cause serious damage to the
mainboard and the AGP graphics cards.
Adding PCI cards
Technical data
32 bit / 33 MHz PCI slots
3,3 V supply voltage
3.3 V auxiliary voltage
Rev. 2.3
