Fujitsu Siemens Computers D1961 - APM and ACPI System Status, Energy-Saving Modes

APM and ACPI system status, energy-saving modes
A26361-D1961-Z120-1-7419, edition 2 English - 29
APM and ACPI system status, energy-saving modes
System
status
ACPI
Status
)
1
APM
Status
Power
LED I
)
2
Power
LED II
)
3
Power
consump
tion
Wake-up
time
Normal
operation
G0 S0 On On/Off On Normal
Simple
energy-saving
mode
S1
Standby Off/On flashing Almost
like
normal
Almost
immediatel
y
Maximum
energy-saving
mode )
4
"Save to
DRAM"
S3 Off/On flashing RAM,
wake-up
compone
nts
approx. 5 s
Maximum
energy-saving
mode **
"Save To
Disk"
G1
S4 Off/Off OFF RAM,
wake-up
compo-
nents
approx. 20
s
”Soft Off" G2 S5 Soft Off Off/Off OFF Nearly
zero
Full boot
time
Mechanically
Off
G3 Off Off/Off OFF Zero Full boot
time
)
1
G = Global status; S = System status
)
2
Two colours
)
3
One colour
)
4
The power supply unit must provide sufficiently loadable 5 V standby voltage.
To use the WOL functionality the power supply must provide a 5 V auxiliary voltage (5VSB) of at
least 1 A.
