FSC B17-1 Service Manual
41
17 Switch the chroma-7120 to RGB-mode (with press “MODE” button )
18 switch the MEM.channel to Channel 03 ( with up or down arrow on chroma 7120 )
19 The lcd-indicator on chroma 7120 will show x = 296 ±10, y = 311 ±10, Y = 190 ±5 cd/m
2
20 Adjust the RED on OSD window until chroma 7120 indicator reached the value R=100
21 adjust the GREEN on OSD, until chroma 7120 indicator reached G=100
22 adjust the BLUE on OSD, until chroma 7120 indicator reached B=100
23 repeat above procedure ( item 5,6,7) until chroma 7120 RGB value meet the tolence =100±2
24 Press Exit on OSD window to save the adjustment result
Turn the POWER-button off to on to quit from factory mode.
10. EDIT Content
D-SUB Connector(Analog)
x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF
00 00 FF FF FF FF FF FF 00 1A B3 58 04 01 00 00 00
16: 0A 0D 01 03 68 22 1B 68 2A 24 1F A1 5A 49 99 25
32: 1A 4C 55 A5 4F 00 81 8F 81 80 61 4F 61 40 45 4F
48: 45 40 01 01 01 01 30 2A 00 98 51 00 2A 40 30 70
64: 13 00 54 0E 11 00 00 1E 00 00 00 FF 00 59 45 47
80: 46 30 30 30 30 30 31 0A 20 20 00 00 00 FD 00 37
96: 4B 1E 53 0E 00 0A 20 20 20 20 20 20 00 00 00 FC
112 00 42 31 37 2D 31 0A 20 20 20 20 20 20 20 00 B7
Note: Byte 0C, 0D, 0E, 0F means Serial No. Byte 10, 11 means Manufacture Time. Byte 7F means checksum
11. BOM List
CBPC780KKDM8 CONVERSION BOARD T780K* 1 PCS
KEPC560KM2 KEY BOARD FOR T560K*SNI 1 PCS
PWPC7425A2 POWER BOARD 1 PCS
2L6008 1 SCREW 2 PCS
15L5862 2 MAIN FRAME 1 PCS
33L4605 BT L HINGE COVER(L) 1 PCS
33L4606 BT L HINGE COVER(R) 1 PCS
34L1156 EF B CONNECTOR COVER 1 PCS
40L 152509 RECYCLE LABEL 0 PCS
40L 152512 RECYCLE LABEL 0 PCS
40L 154501 1 HI-POT GND LABEL FOR MO 1 PCS
40L 190622 3A ID LABEL 1 PCS
40L 581 26668 SLZ LABEL 1 PCS
41L1700622 3A MANUAL 1 PCS
41L7800622 3A SET UP GUIDE 1 PCS
