FSC B17-1 Service Manual
4
1. MONITOR SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 38.1cm(15.0")
Pixel pitch 0.297mm( H )x 0.297mm( V )
Viewable angle 130˚ (H) 90˚ (V)
Response time (typ.) 25 ms
Video Analog/DVI-D
Input Sync. Type H/V TTL Separate and Composite Sync.
H-Frequency 30kHz – 63kHz
V-Frequency 55-75Hz
Display Colors Over 16 million Colors
Dot Clock 80MHz
Max. Resolution 1024 x 768
Plug & Play VESA DDC2B
TM
Power Consumption ON Mode
<35W
OFF Mode
<1W
Maximum Screen Size
Horizontal : 12.0”(304.128mm)
Vertical : 9.0”(228.096mm)
Power Source
90~264VAC,47~63Hz
Environmental
Considerations
Operating Temp: 5°C to 40°C
Storage Temp.: -5°C to 40°C
Operating Humidity : 10% to 80%
Weight (N. W.) Packaged 4.6Kgs Unit
Unpackaged 6.3Kgs Unit
