8.1 Scanner Settings
Item Explanation Selectable parameter Default
Multifeed Select the method to detect
Multifeed. (Check either of
overlapping or document
length, or both of document
length and overlapping)
None/Check Overlapping [Ultrasonic]/
Check Length/Check Overlapping and
Length.
Selectable length (to be detected as
length difference): 10, 15 or 20 mm
Check
overlapping
Page edge filler
Fill the end sections of a
specified-mm-wide with
white or black on the
scanned image.
When the backing
(background) color is white,
the end sections are filed
with white; and when the
background color is black,
filled with black.
ADF:
Top/left/right: 0-15 mm
Bottom: -7 to 7 mm (can be set in
increments of 1 mm)
FB:
Top/bottom/left/right:0-15 mm
(A: Image area B: Filled area
A+B: Area to be output)
Top/Bottom/
Left/Right:
0 mm
Dropout Color Drop out a preselected color
for the scanned image.
(Binary black & white/
grayscale mode only)
Red/Green/Blue/None Green
Prepick To give a higher priority to
processing speed, select
[Yes], if not, select [No].
Yes/No Yes
Document check area
specification for
Multifeed Detection
Selected range: This is
checked when limiting the
range of detecting
multifeeds. You can
determine if mulfifeed
detection is enabled or
disabled in the specified
area.
Checking of selected range Do not check
Enable/Disable (when the selected
range is checked)
Disable
Start: The start point of the
check area in length (mm)
from top edge of the
document is specified.
0 to 510 mm (with 2 mm increment) 0 mm
End: The end point of the
check area in length (mm)
from top edge of the
document is specified.
0 to 510 mm (with 2 mm increment) 0 mm
