En-35
1. SEPARATION TUBE KIT
Table 9-1 shows a outdoor unit branch kit that is used for installing multiple outdoor units. Table 9-2 shows separation tubes used for
connection between outdoor and indoor units. Refer to the installation instruction sheet for the outdoor unit branch kit and the
separation tubes for installation specifications.
9. OPTION PARTS
CAUTION
Listed below are option parts used exclusively with the R410A refrigerant.
Do not use parts other than those listed below.
Table 9-2 Separation tube selection
Table 9-3 Header selection
2. HEADER
A header is used for connecting the indoor units. Refer to the installation instruction sheet for the header for installation specifica-
tions.
Table 9-1 Outdoor unit branch kit for installing multiple outdoor units
Outdoor unit branch kit Total model code of outdoor unit
UTR-CP567L
UTR-CP567X ALL
UTR-CP567Q
Separation tube Total model code of indoor unit
UTR-BP090L
UTR-BP090X 90 or less
UTR-BP090Q
UTR-BP180L
UTR-BP180X 91 to 180
UTR-BP180Q
UTR-BP567L
UTR-BP567X 181 or more
UTR-BP567Q
Header Total model code
6 Branches 8 Branches of outdoor unit
UTR-H0906L UTR-H0908L 90 or less
UTR-H1806L UTR-H1808L 91 to 180
