Unit : mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASAG07LJCA, ASAG09LJCA, ASAG12LJCA
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LUCA, ASYG09LUCA, ASYG12LUCA
205 : Installed state
*1: Vertical flap is downward
203
140 *1
10 *1
145 *1
790
280
2011.12.09 9
INDOOR UNIT
WALL MOUNTED
ASAG18LFCA, ASAG24LFCA
998
238
320
282
185
870
