Fujitsu AOAG30LAT4 User Manual

INDOOR UNIT
COMPACT CASSETTE
AUAG09LVLA
AUAG12LVLA
AUAG14LVLA
AUAG18LVLA
2012.01.23 10
Drain hose I.D. 3/4 in. , O.D. 1-1/16 in.
Unit : mm
DECORATION PANEL
UTG-UFYD-W
530 : Hanging bolt position
102
135
250
700
700
75
30
30
262
540 : Hanging bolt position
570 : Indoor unit
580 to 660
Ceiling openings
Decoration panel mounting state
Top view
150 to 200Min. 450
Min. 450
Maintenance space
Side view
215
123
58
114
146
108
102
245
30
40 99
Drain port
Ceiling
Drain port
Be sure to leave
maintenance space
for future service
at the designated
position.
30
49
