Fujitsu AOYG09LLCE Design & Technical Manual

4-2. Heating capacity
¢
Model:ASYG07LLCE
AFR
m
3
/h
740
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.42 1.22 2.36 1.24 2.30 1.27 2.24 1.30 2.19 1.32
-10 -11 2.51 1.17 2.45 1.20 2.39 1.22 2.33 1.24 2.27 1.27
-5 -7 2.75 1.15 2.68 1.18 2.61 1.20 2.55 1.23 2.48 1.25
0 -2 3.18 1.18 3.10 1.21 3.03 1.23 2.95 1.26 2.87 1.28
5 3 3.61 1.21 3.52 1.23 3.44 1.26 3.35 1.28 3.26 1.31
7 6 3.78 1.22 3.69 1.25 3.60 1.27 3.51 1.30 3.42 1.32
10 8 3.80 1.18 3.71 1.21 3.62 1.23 3.53 1.26 3.44 1.28
15 10 3.98 1.19 3.89 1.22 3.79 1.24 3.70 1.27 3.60 1.29
¢
Model:ASYG09LLCE
AFR
m
3
/h
740
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.63 1.23 2.56 1.25 2.50 1.28 2.44 1.31 2.38 1.33
-10 -11 2.72 1.18 2.66 1.21 2.59 1.23 2.53 1.25 2.46 1.28
-5 -7 2.96 1.16 2.88 1.19 2.81 1.21 2.74 1.24 2.67 1.26
0 -2 3.39 1.20 3.31 1.22 3.23 1.25 3.14 1.27 3.06 1.30
5 3 3.82 1.23 3.73 1.25 3.64 1.28 3.54 1.30 3.45 1.33
7 6 3.99 1.24 3.90 1.27 3.80 1.29 3.71 1.32 3.61 1.34
10 8 3.94 1.18 3.84 1.21 3.75 1.23 3.66 1.26 3.56 1.28
15 10 4.11 1.19 4.01 1.22 3.91 1.24 3.81 1.27 3.71 1.29
¢
Model:ASYG12LLCE
AFR
m
3
/h
740
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 3.17 1.39 3.10 1.42 3.02 1.45 2.94 1.48 2.87 1.51
-10 -11 3.35 1.44 3.27 1.47 3.20 1.50 3.12 1.53 3.04 1.56
-5 -7 3.72 1.48 3.63 1.51 3.54 1.54 3.45 1.57 3.37 1.60
0 -2 4.36 1.51 4.25 1.54 4.15 1.57 4.05 1.60 3.94 1.63
5 3 5.00 1.53 4.88 1.57 4.76 1.60 4.64 1.63 4.52 1.66
7 6 5.25 1.55 5.13 1.58 5.00 1.61 4.88 1.64 4.75 1.67
10 8 4.90 1.38 4.78 1.41 4.66 1.44 4.55 1.47 4.43 1.50
15 10 5.15 1.39 5.02 1.42 4.90 1.45 4.78 1.48 4.66 1.51
DESIGN & TECHNICAL MANUAL
- 8 -
WALL MOUNTED ASYG07-12LLCE
