Fujitsu AOYG18KBTA3 Design & Technical Manual

AOYG24KBTA3
Combination no. Unit 1 Unit 2 Unit 3 Total
1 7 7 — 14
2 7 9 — 16
3 7 12 — 19
4 7 14 — 21
5 7 18 — 25
6 9 9 — 18
7 9 12 — 21
8 9 14 — 23
9 9 18 — 27
10 12 12 — 24
11 12 14 — 26
12 12 18 — 30
13 14 14 — 28
13 14 18 — 32
14 7 7 7 21
15 7 7 9 23
16 7 7 12 26
17 7 7 14 28
18 7 7 18 32
19 7 9 9 25
20 7 9 12 28
21 7 9 14 30
22 7 9 18 34
23 7 12 12 31
25 7 12 14 33
26 7 14 14 35
27 9 9 9 27
28 9 9 12 30
29 9 9 14 32
30 9 9 18 36
31 9 12 12 33
32 9 12 14 35
33 12 12 12 36
Numbers in column Unit 1, 2, 3, and Total indicate the indoor unit capacities as follows:
7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h ....
- 6 -
1-2. Indoor unit connection patterns 1. Model lineup
3-UNIT MULTI-SPLIT TYPE 3-UNIT MULTI-SPLIT TYPE

Fujitsu AOYG18KBTA3 Specifications

General

Brand	Fujitsu
Model	AOYG18KBTA3
Category	Air Conditioner
Language	English
