Fujitsu AOYG18KBTA3 Design & Technical Manual

1-2. Indoor unit connection patterns
¢ 3-unit multi-split type
AOYG18KBTA3
Combination no. Unit 1 Unit 2 Unit 3 Total
1 7 7 — 14
2 7 9 — 16
3 7 12 — 19
4 7 14 — 21
5 9 9 — 18
6 9 12 — 21
7 9 14 — 23
8 12 12 — 24
9 12 14 — 26
10 14 14 — 28
11 7 7 7 21
12 7 7 9 23
13 7 7 12 26
14 7 7 14 28
15 7 9 9 25
16 7 9 12 28
17 7 9 14 30
18 9 9 9 27
19 9 9 12 30
Numbers in column Unit 1, 2, 3, and Total indicate the indoor unit capacities as follows:
7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h ....
- 5 -
1-2. Indoor unit connection patterns 1. Model lineup
3-UNIT MULTI-SPLIT TYPE 3-UNIT MULTI-SPLIT TYPE

Fujitsu AOYG18KBTA3 Specifications

General

Brand	Fujitsu
Model	AOYG18KBTA3
Category	Air Conditioner
Language	English
