Fujitsu AOYG18KBTA3 Design & Technical Manual

¢ Model: ASYG18KMTB
Unit: mm
980 240
280
Outline of indoor unit
for pipe inlet Ø65for pipe inlet Ø65
37 37
400 9041377
7341761 429
115
72
417
482
510
- 41 -
4-4. Wall mounted type 4. Dimensions
3-UNIT MULTI-SPLIT TYPE 3-UNIT MULTI-SPLIT TYPE
