Fujitsu AOYG18KBTA3 Design & Technical Manual

6. Capacity table
6-1. Combinations
¢
Model: AOYG18KBTA3

Cooling
Combination of indoor unit
Rated capacity for each in-
door unit (kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 1 2 3
7 7 — 14 2.00 2.00 — 1.8 4.00 5.0 0.35 0.86 1.35 4.65 4.0 8.3 A++
7 9 — 16 2.00 2.50 — 1.8 4.50 5.7 0.35 1.03 1.54 4.36 4.5 8.2 A++
7 12 — 19 1.99 3.41 — 1.8 5.40 6.8 0.35 1.41 1.85 3.83 5.4 8.0 A++
7 14 — 21 1.80 3.60 — 1.8 5.40 7.0 0.35 1.41 1.90 3.83 5.4 8.0 A++
9 9 — 18 2.50 2.50 — 1.8 5.00 6.4 0.35 1.23 1.74 4.06 5.0 8.1 A++
9 12 — 21 2.31 3.09 — 1.8 5.40 7.0 0.35 1.41 1.90 3.83 5.4 8.0 A++
9 14 — 23 2.11 3.29 — 1.8 5.40 7.0 0.35 1.41 1.90 3.83 5.4 8.0 A++
12 12 — 24 2.70 2.70 — 1.8 5.40 7.0 0.35 1.41 1.90 3.83 5.4 8.0 A++
12 14 — 26 2.49 2.91 — 1.8 5.40 7.0 0.35 1.41 1.90 3.83 5.4 8.0 A++
14 14 — 28 2.70 2.70 — 1.8 5.40 7.0 0.35 1.41 1.90 3.83 5.4 8.0 A++
7 7 7 21 1.80 1.80 1.80 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
7 7 9 23 1.64 1.64 2.12 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
7 7 12 26 1.45 1.45 2.50 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
7 7 14 28 1.35 1.35 2.70 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
7 9 9 25 1.52 1.94 1.94 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
7 9 12 28 1.35 1.74 2.31 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
7 9 14 30 1.26 1.62 2.52 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
9 9 9 27 1.80 1.80 1.80 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
9 9 12 30 1.62 1.62 2.16 1.8 5.40 7.0 0.35 1.13 1.90 4.78 5.4 8.6 A+++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h
• The above is the value for connecting with wall-mounted type indoor unit.
• 2 or more indoor units should be connected.
• Cooling: Indoor temperature of 27 °CDB/19 °CWB and outdoor temperature of 35 °CDB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor unit is from 14,000 Btu/h up to 30,000 Btu/h.
