Fujitsu AOYG18KBTA3 Design & Technical Manual

6-2. Cooling capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOYG18KBTA3
Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
30
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
28
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
27
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
26
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
25
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
24
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
23
-10.0
5.5 0.88 6.2 0.89 6.5 0.90 7.0 0.91 7.5 0.92 7.7 0.92
0.0 5.5 1.04 6.2 1.06 6.5 1.07 7.0 1.08 7.5 1.10 7.7 1.10
5.0 5.5 1.11 6.2 1.13 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.17
10.0 5.5 1.21 6.2 1.23 6.5 1.24 7.0 1.25 7.5 1.27 7.7 1.28
15.0 5.5 1.12 6.2 1.14 6.5 1.14 7.0 1.16 7.5 1.17 7.7 1.18
20.0 5.5 1.05 6.2 1.07 6.5 1.07 7.0 1.09 7.5 1.10 7.7 1.10
25.0 5.5 1.28 6.2 1.31 6.5 1.32 7.0 1.33 7.5 1.35 7.7 1.35
30.0 5.5 1.48 6.2 1.50 6.5 1.51 7.0 1.53 7.5 1.55 7.7 1.56
35.0 5.5 1.84 6.2 1.87 6.5 1.89 7.0 1.91 7.5 1.93 7.7 1.94
40.0 4.9 1.75 5.5 1.78 5.8 1.80 6.2 1.82 6.6 1.84 6.8 1.85
46.0 4.2 1.66 4.8 1.69 5.0 1.71 5.4 1.72 5.8 1.74 6.0 1.75
- 354 -
6-2. Cooling capacity 6. Capacity table
