Model: AOYG24KBTA3
Cooling
Combination of indoor unit
Rated capacity for each
indoor unit (kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 1 2 3
7 7 14 2.00 2.00 1.8 4.00 5.0 0.35 0.86 1.35 4.65 4.0 8.3 A++
7 9 16 2.00 2.50 1.8 4.50 5.7 0.35 1.03 1.54 4.36 4.5 8.2 A++
7 12 19 2.00 3.50 1.8 5.50 6.8 0.35 1.46 1.85 3.77 5.5 8.0 A++
7 14 21 2.00 4.00 1.8 6.00 7.5 0.35 1.73 2.20 3.48 6.0 7.6 A++
7 18 25 1.90 4.90 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
9 9 18 2.50 2.50 1.8 5.00 6.4 0.35 1.23 1.74 4.06 5.0 8.1 A++
9 12 21 2.50 3.50 1.8 6.00 7.5 0.35 1.73 2.20 3.48 6.0 7.6 A++
9 14 23 2.50 4.00 1.8 6.50 8.2 0.35 2.04 2.46 3.19 6.5 7.2 A++
9 18 27 2.27 4.53 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
12 12 24 3.40 3.40 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
12 14 26 3.14 3.66 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
12 18 30 2.72 4.08 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
14 14 28 3.40 3.40 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
14 18 32 2.98 3.82 1.8 6.80 8.5 0.35 2.26 2.65 3.01 6.8 6.9 A++
7 7 7 21 2.00 2.00 2.00 1.8 6.00 7.5 0.35 1.37 2.20 4.37 6.0 8.6 A+++
7 7 9 23 2.00 2.00 2.50 1.8 6.50 8.2 0.35 1.59 2.46 4.08 6.5 8.5 A+++
7 7 12 26 1.83 1.83 3.14 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 7 14 28 1.70 1.70 3.40 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 7 18 32 1.49 1.49 3.82 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 9 9 25 1.90 2.45 2.45 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 9 12 28 1.70 2.19 2.91 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 9 14 30 1.59 2.04 3.17 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 9 18 34 1.40 1.80 3.60 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 12 12 31 1.54 2.63 2.63 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 12 14 33 1.44 2.47 2.89 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
7 14 14 35 1.36 2.72 2.72 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
9 9 9 27 2.27 2.27 2.27 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
9 9 12 30 2.04 2.04 2.72 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
9 9 14 32 1.91 1.91 2.98 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
9 9 18 36 1.70 1.70 3.40 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
9 12 12 33 1.86 2.47 2.47 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
9 12 14 35 1.75 2.33 2.72 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
12 12 12 36 2.27 2.27 2.27 1.8 6.80 8.5 0.35 1.74 2.65 3.90 6.8 8.5 A+++
NOTES:
7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h
The above is the value for connecting with wall-mounted type indoor unit.
2 or more indoor units should be connected.
Cooling: Indoor temperature of 27 °CDB/19 °CWB and outdoor temperature of 35 °CDB.
Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
The total ability of connected indoor units is from 14,000 Btu/h up to 36,000 Btu/h.
