Fujitsu AOYG18KBTA3 Design & Technical Manual


Heating
Combination of indoor unit
Rated capacity for each in-
door unit (kW)
Total capacity
(kW)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 1 2 3
7 7 — 14 2.40 2.40 — 2.0 4.80 5.6 0.25 1.00 1.30 4.80 4.0 4.2 A+
7 9 — 16 2.40 3.00 — 2.0 5.40 6.4 0.25 1.21 1.48 4.45 4.0 4.2 A+
7 12 — 19 2.40 4.20 — 2.0 6.60 7.6 0.25 1.66 1.76 3.98 5.0 4.0 A+
7 14 — 21 2.40 4.80 — 2.0 7.20 8.4 0.25 1.86 2.07 3.87 5.4 4.0 A+
7 18 — 25 2.16 5.54 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
9 9 — 18 3.00 3.00 — 2.0 6.00 7.2 0.25 1.44 1.67 4.17 4.5 4.1 A+
9 12 — 21 3.00 4.20 — 2.0 7.20 8.4 0.25 1.86 2.07 3.87 5.4 4.0 A+
9 14 — 23 2.96 4.74 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
9 18 — 27 2.57 5.13 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
12 12 — 24 3.85 3.85 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
12 14 — 26 3.55 4.15 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
12 18 — 30 3.08 4.62 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
14 14 — 28 3.85 3.85 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
14 18 — 32 3.37 4.33 — 2.0 7.70 9.2 0.25 2.01 2.35 3.83 5.8 4.0 A+
7 7 7 21 2.40 2.40 2.40 2.0 7.20 8.4 0.25 1.61 2.07 4.48 5.4 4.7 A++
7 7 9 23 2.40 2.40 3.00 2.0 7.80 9.2 0.25 1.76 2.35 4.42 5.8 4.6 A++
7 7 12 26 2.15 2.15 3.70 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 7 14 28 2.00 2.00 4.00 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 7 18 32 1.75 1.75 4.50 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 9 9 25 2.24 2.88 2.88 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 9 12 28 2.00 2.57 3.43 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 9 14 30 1.87 2.40 3.73 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 9 18 34 1.65 2.12 4.23 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 12 12 31 1.80 3.10 3.10 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 12 14 33 1.70 2.91 3.39 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
7 14 14 35 1.60 3.20 3.20 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
9 9 9 27 2.67 2.67 2.67 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
9 9 12 30 2.40 2.40 3.20 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
9 9 14 32 2.25 2.25 3.50 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
9 9 18 36 2.00 2.00 4.00 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
9 12 12 33 2.18 2.91 2.91 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
9 12 14 35 2.06 2.74 3.20 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
12 12 12 36 2.67 2.67 2.67 2.0 8.00 9.2 0.25 1.82 2.35 4.40 6.0 4.6 A++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h
• The above is the value for connecting with wall-mounted type indoor unit.
• 2 or more indoor units should be connected.
• Heating: Indoor temperature of 20 °CDB, and outdoor temperature of 7 °CDB/6 °CWB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor units is from 14,000 Btu/h up to 36,000 Btu/h.
- 353 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
