Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
14
-15.0
-16.0 3.9 1.77 3.8 1.81 3.8 1.84 3.7 1.88 3.6 1.92
-10.0 -11.0 4.4 1.87 4.3 1.91 4.2 1.95 4.1 1.99 4.0 2.03
-5.0 -7.0 4.7 1.71 4.6 1.74 4.5 1.78 4.4 1.81 4.3 1.85
0.0 -2.0 5.4 1.52 5.3 1.55 5.2 1.59 5.0 1.62 4.9 1.65
5.0 3.0 5.9 1.48 5.7 1.51 5.6 1.54 5.5 1.58 5.3 1.61
7.0 6.0 5.9 1.30 5.7 1.33 5.6 1.36 5.5 1.38 5.3 1.41
10.0 8.0 5.9 1.22 5.7 1.25 5.6 1.27 5.5 1.30 5.3 1.32
15.0 10.0 5.9 1.11 5.7 1.13 5.6 1.15 5.5 1.18 5.3 1.20
20.0 15.0 5.9 0.94 5.7 0.95 5.6 0.97 5.5 0.99 5.3 1.01
24.0 18.0 5.9 0.84 5.7 0.86 5.6 0.87 5.5 0.89 5.3 0.91
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 14,000 Btu/h up to 36,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 410 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT
AOYG18-24KBTA3
OUTDOOR UNIT
AOYG18-24KBTA3
