2. Dimensions
2-1. Models: ABYG18KRTA and ABYG22KRTA
Unit: mm
Side view Top view
Rear view
Suspension bolt pitch
923
Indoor unit (Top view)
Indoor unit
Dimensions
(Space required for installation)
The length of the bolt
here is 30 mm.
75
10
175290
75
49 84
55
110
923
1,080
145
181
349
119 98
125 103
235
100
125
91
80140
705
206
179
115
41
290178
313
89
ø100-mm hole
89
110
- 8 -
2-1. Models: ABYG18KRTA and ABYG22KRTA 2. Dimensions
CEILING TYPE
ABYG18-45KRTA
CEILING TYPE
ABYG18-45KRTA
