Fujitsu ARHG09LLTA

5. CONTROL SYSTEM
SYSTEM DIAGRAM

1 remote controller


2 remote controllers
Primary Secondary
A BC
Indoor unit Indoor unit
Remote controller Remote controllers
A , B , C : Remote controller cable.
A
<
=
500m ; B+C
<
=
500m
ELECTRICAL WIRING

1 remote controller


2 remote controllers
Indoor unit
REMOTE
CONTROLLER
123
123
Primary
Secondary
Indoor unit
123
123 123
REMOTE
CONTROLLER
Remote controller Remote controllers
1 (RED) : 12V
2 (WHITE) : Signal
3 (BLACK) : COM
DIMENSIONS

83.5
15.3
63.5
Hole
45.3
4.54.5
4.5
9
12.5
Hole x 2
Hole x 3
6
30 33.5
23
120
120
(120)
18
Front View Side View Rear View
[Unit : mm]
- (05 - 27) -
CONTROL SYSTEM CONTROL SYSTEM
