Accessories

Part name Exterior Q’ty Part name Exterior Q’ty

Installation manual 1 Screw A

10 mm

Operating manual 1 Screw B

10 mm

Grille 1 Cable clip 2

Bracket frame 1 Cable tie 3

Bushing 1

- 211 -

10-3. Auto louver grille kit (UTD-GXTB-W) 10. Optional parts installation
