Fujitsu ARXG24KMLA - Slim duct type

6-3. Model: AOYG54KRTA
TC: Total Capacity, SHC: Sensible Heat Capacity, IP: Input Power
¢
Cooling capacity (Twin)

Compact cassette type
Model: AUXG24KVLA × 2
AFR
m
3
/h
1,860
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 9.76 7.44 1.93 10.59 7.82 1.97 11.14 8.07 2.00 11.69 8.40 2.03 12.25 8.74 2.06 12.76 8.90 2.07 13.52 9.14 2.09
-10 9.73 7.40 1.93 10.55 7.78 1.97 11.10 8.03 2.00 11.65 8.36 2.03 12.21 8.69 2.06 12.72 8.86 2.08 13.48 9.10 2.10
0 9.66 7.32 1.94 10.48 7.70 1.98 11.03 7.94 2.01 11.58 8.27 2.04 12.13 8.61 2.07 12.63 8.76 2.08 13.39 9.00 2.11
5 9.49 7.30 1.99 10.30 7.67 2.03 10.84 7.92 2.06 11.37 8.25 2.09 11.91 8.58 2.12 12.41 8.74 2.14 13.15 8.97 2.16
10 9.32 7.28 2.04 10.11 7.64 2.08 10.64 7.89 2.11 11.17 8.22 2.14 11.70 8.55 2.17 12.18 8.71 2.19 12.92 8.94 2.22
15 9.16 7.16 2.10 9.94 7.52 2.14 10.46 7.76 2.17 10.98 8.09 2.21 11.50 8.41 2.24 11.98 8.56 2.25 12.70 8.80 2.28
20 12.24 8.51 3.76 13.27 8.94 3.84 13.97 9.23 3.90 14.66 9.62 3.96 15.35 10.00 4.01 16.00 10.19 4.04 16.96 10.46 4.09
25 11.72 8.30 3.89 12.71 8.72 3.97 13.38 9.00 4.03 14.04 9.37 4.09 14.70 9.75 4.15 15.32 9.93 4.18 16.24 10.20 4.23
30 11.20 8.08 4.02 12.15 8.49 4.11 12.78 8.77 4.16 13.42 9.13 4.22 14.05 9.50 4.28 14.64 9.67 4.32 15.52 9.94 4.37
35 10.68 7.87 4.14 11.59 8.27 4.24 12.19 8.54 4.30 12.80 8.89 4.36 13.40 9.25 4.42 13.96 9.42 4.45 14.80 9.67 4.51
40 9.10 6.93 3.73 9.88 7.28 3.82 10.39 7.51 3.87 10.91 7.83 3.93 11.42 8.14 3.98 11.90 8.29 4.01 12.62 8.52 4.06
46 7.21 5.80 3.24 7.83 6.09 3.31 8.23 6.29 3.36 8.64 6.55 3.41 9.05 6.81 3.46 9.43 6.94 3.48 10.00 7.13 3.52

Duct type
Model: ARXG24KMLA × 2
AFR
m
3
/h
2,200
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 9.76 7.44 1.93 10.59 7.82 1.97 11.14 8.07 2.00 11.69 8.40 2.03 12.25 8.74 2.06 12.76 8.90 2.07 13.52 9.14 2.09
-10 9.73 7.40 1.93 10.55 7.78 1.97 11.10 8.03 2.00 11.65 8.36 2.03 12.21 8.69 2.06 12.72 8.86 2.08 13.48 9.10 2.10
0 9.66 7.32 1.94 10.48 7.70 1.98 11.03 7.94 2.01 11.58 8.27 2.04 12.13 8.61 2.07 12.63 8.76 2.08 13.39 9.00 2.11
5 9.49 7.30 1.99 10.30 7.67 2.03 10.84 7.92 2.06 11.37 8.25 2.09 11.91 8.58 2.12 12.41 8.74 2.14 13.15 8.97 2.16
10 9.32 7.28 2.04 10.11 7.64 2.08 10.64 7.89 2.11 11.17 8.22 2.14 11.70 8.55 2.17 12.18 8.71 2.19 12.92 8.94 2.22
15 9.16 7.16 2.10 9.94 7.52 2.14 10.46 7.76 2.17 10.98 8.09 2.21 11.50 8.41 2.24 11.98 8.56 2.25 12.70 8.80 2.28
20 12.24 8.51 3.76 13.27 8.94 3.84 13.97 9.23 3.90 14.66 9.62 3.96 15.35 10.00 4.01 16.00 10.19 4.04 16.96 10.46 4.09
25 11.72 8.30 3.89 12.71 8.72 3.97 13.38 9.00 4.03 14.04 9.37 4.09 14.70 9.75 4.15 15.32 9.93 4.18 16.24 10.20 4.23
30 11.20 8.08 4.02 12.15 8.49 4.11 12.78 8.77 4.16 13.42 9.13 4.22 14.05 9.50 4.28 14.64 9.67 4.32 15.52 9.94 4.37
35 10.68 7.87 4.14 11.59 8.27 4.24 12.19 8.54 4.30 12.80 8.89 4.36 13.40 9.25 4.42 13.96 9.42 4.45 14.80 9.67 4.51
40 9.10 6.93 3.73 9.88 7.28 3.82 10.39 7.51 3.87 10.91 7.83 3.93 11.42 8.14 3.98 11.90 8.29 4.01 12.62 8.52 4.06
46 7.21 5.80 3.24 7.83 6.09 3.31 8.23 6.29 3.36 8.64 6.55 3.41 9.05 6.81 3.46 9.43 6.94 3.48 10.00 7.13 3.52
- 70 -
6-3. Model: AOYG54KRTA 6. Capacity table
OUTDOOR UNIT AOYG36-54KRTA OUTDOOR UNIT AOYG36-54KRTA
