OUTDOOR UNIT AO 18-24L2
OUTDOOR UNIT AO 18-24L2
MODELS : INDOOR UNIT 14000BTU (AO 18L2, AO 24L2)
Indoor unit
Height difference H
Connection pipe
H
Outdoor unit
Indoor unit
Connection pipe
H
Outdoor unit
Indoor unit is upper than outdoor unit.
1
Indoor unit is under than outdoor unit.
2
5 7.5 10 15 20
10 - - 1.000 0.997 0.989
7.5 - 1.000 1.000 0.997 0.989
5 1.000 1.000 1.000 0.997 0.989
0 1.000 1.000 1.000 0.997 0.989
-5 0.992 0.992 0.992 0.989 0.981
-7.5 - 0.988 0.988 0.985 0.977
-10 - - 0.984 0.981 0.973
COOLING
Pipe length (m)
Height difference H
(m)
*1
Indoor unit is upper
than outdoor unit
*2
Indoor unit is under
than outdoor unit
5 7.5 10 15 20
10 - - 0.982 0.960 0.915
7.5 - 0.993 0.984 0.962 0.918
5 1.001 0.995 0.987 0.965 0.920
0 1.006 1.000 0.992 0.969 0.925
-5 1.006 1.000 0.992 0.969 0.925
-7.5 - 1.000 0.992 0.969 0.925
-10 - - 0.992 0.969 0.925
HEATING
Pipe length (m)
Height difference H
(m)
*1
Indoor unit is upper
than outdoor unit
*2
Indoor unit is under
than outdoor unit
