Model name ASU9RLS2 ASU12RLS2 ASU15RLS2
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—264 V
Capacity Btu/h class 9,000 12,000 14,000
Input power W 16 19 23
Running current A 0.14 0.17 0.20
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
353 (600) 388 (660) 418 (710)
MED 324 (550) 353 (600) 377 (640)
LOW 277 (470) 312 (530) 336 (570)
QUIET 194 (330) 194 (330) 230 (390)
Heating
HIGH 353 (600) 388 (660) 418 (710)
MED 324 (550) 353 (600) 377 (640)
LOW 277 (470) 312 (530) 347 (590)
QUIET 194 (330) 194 (330) 253 (430)
Type × Q'ty Cross flow ×1
Motor output W 36
Sound pressure level *
Cooling
HIGH
dB (A)
36 37 41
MED 32 34 36
LOW 28 31 33
QUIET 21 21 25
Heating
HIGH 36 37 41
MED 32 34 36
LOW 28 31 34
QUIET 21 21 27
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main: 12-5/8 × 27-3/16 × 13/16 (320 × 690 × 20)
Sub: 3-5/16 × 27-3/16 × 1/2 (84 × 690 × 13.3)
Fin pitch FPI Main: 23, Sub: 18
Rows × Stages Main: 2 × 20, Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
(Approximate color of Munsell N 9.25/)
Dimensions
(H × W × D)
Net
in (mm)
11-1/8 × 34-1/4 × 7-5/16 (282 x 870 x 185)
Gross 9-3/4 × 36-1/4 × 14-11/16 (247 x 920 x 373)
Weight
Net
lb (kg)
21 (9.5)
Gross 27 (12)
Connection
pipe
Size
Liquid
mm (in)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø 1/2(Ø 12.70)
Method Flare
Drain hose
Material PP + LLDPE
Size in (mm) Ø 9/16(I.D.), Ø 5/8 to Ø 11/16(O.D.) [Ø 13.8(I.D.), Ø 15.8 to Ø 16.7(O.D.)]
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Remote controller type Wireless (Wired [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 10 -
2-3. Wall mounted type 2. Specifications
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
