Installation space
40 (1,000)
or more
40 (1,000)
or more
95 (2,400)
or more
11 (262)
or more
Strong and durable ceiling
Obstruction
Floor
Unit: in (mm)
Maximum height from floor to ceiling [Unit: in (mm)]
Model name AUU7RLF and AUU9RLF AUU12RLF and AUU18RLF
Standard mode
107
(2,700)
High ceiling mode —
119
(3,000)
• 3-way direction setting
4 (100) or more*
Unit: in (mm)
NOTES:
• *: When installing the indoor unit, be careful about the maintenance space.
• To set “3-direction”, optional Air outlet shutter plate (UTR-YDZB) must be installed, and the “out-
let-direction” need to be switched to “3-way” by remote controller.
• The ceiling height cannot be set in the 3-way outlet mode. Therefore, ceiling height setting
change by function setting 20 is prohibited. For details, refer to "Contents of function setting" on
page 149.
- 15 -
3-1. Compact cassette type 3. Dimensions
MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
