 Indoor units: 7,000 Btu + 18,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.91 2.52 16.37 2.59 15.82 2.67 15.27 2.74 14.93 2.79
14 12 19.83 2.63 19.21 2.71 18.56 2.79 17.91 2.86 17.51 2.91
23 19 22.39 2.70 21.68 2.77 20.95 2.85 20.22 2.93 19.77 2.98
32 28 25.29 2.70 24.49 2.77 23.66 2.85 22.83 2.93 22.33 2.98
41 37 28.18 2.70 27.29 2.77 26.37 2.85 25.44 2.93 24.88 2.98
47 43 29.93 2.77 28.98 2.85 28.00 2.93 27.02 3.00 26.43 3.00
50 47 30.91 2.72 29.94 2.80 28.93 2.88 27.91 2.96 27.30 3.00
59 50 30.77 2.25 29.80 2.31 28.79 2.38 27.78 2.45 27.17 2.49
68 59 29.85 1.89 28.91 1.94 27.93 2.00 26.95 2.06 26.36 2.09
75 65 29.96 1.87 29.01 1.92 28.03 1.98 27.05 2.03 26.45 2.07
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.96 2.52 4.80 2.59 4.64 2.67 4.47 2.74 4.38 2.79
-10.0 -11.1 5.81 2.63 5.63 2.71 5.44 2.79 5.25 2.86 5.13 2.91
-5.0 -7.2 6.56 2.70 6.36 2.77 6.14 2.85 5.93 2.93 5.80 2.98
0.0 -2.2 7.41 2.70 7.18 2.77 6.93 2.85 6.69 2.93 6.54 2.98
5.0 2.8 8.26 2.70 8.00 2.77 7.73 2.85 7.46 2.93 7.29 2.98
8.3 6.1 8.77 2.77 8.49 2.85 8.21 2.93 7.92 3.00 7.74 3.00
10.0 8.3 9.06 2.72 8.77 2.80 8.48 2.88 8.18 2.96 8.00 3.00
15.0 10.0 9.02 2.25 8.73 2.31 8.44 2.38 8.14 2.45 7.96 2.49
20.0 15.0 8.75 1.89 8.47 1.94 8.19 2.00 7.90 2.06 7.73 2.09
23.9 18.3 8.78 1.87 8.50 1.92 8.22 1.98 7.93 2.03 7.75 2.07
 Indoor units: 9,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 15.61 2.49 15.12 2.56 14.61 2.64 14.10 2.71 13.79 2.76
14 12 18.36 2.63 17.78 2.71 17.17 2.78 16.57 2.86 16.21 2.91
23 19 20.21 2.59 19.57 2.67 18.91 2.74 18.25 2.82 17.85 2.87
32 28 22.62 2.52 21.91 2.59 21.17 2.66 20.43 2.74 19.98 2.78
41 37 25.05 2.44 24.26 2.51 23.44 2.58 22.62 2.66 22.12 2.70
47 43 26.72 2.54 25.88 2.61 25.00 2.69 24.13 2.77 23.59 2.81
50 47 28.02 2.54 27.14 2.61 26.22 2.68 25.30 2.76 24.74 2.80
59 50 28.33 2.21 27.44 2.27 26.51 2.34 25.58 2.40 25.02 2.44
68 59 25.14 1.85 24.35 1.91 23.52 1.96 22.70 2.02 22.20 2.05
75 65 24.63 1.51 23.86 1.55 23.05 1.60 22.24 1.64 21.75 1.67
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.58 2.49 4.43 2.56 4.28 2.64 4.13 2.71 4.04 2.76
-10.0 -11.1 5.38 2.63 5.21 2.71 5.03 2.78 4.86 2.86 4.75 2.91
-5.0 -7.2 5.92 2.59 5.74 2.67 5.54 2.74 5.35 2.82 5.23 2.87
0.0 -2.2 6.63 2.52 6.42 2.59 6.20 2.66 5.99 2.74 5.85 2.78
5.0 2.8 7.34 2.44 7.11 2.51 6.87 2.58 6.63 2.66 6.48 2.70
8.3 6.1 7.83 2.54 7.58 2.61 7.33 2.69 7.07 2.77 6.91 2.81
10.0 8.3 8.21 2.54 7.95 2.61 7.68 2.68 7.42 2.76 7.25 2.80
15.0 10.0 8.30 2.21 8.04 2.27 7.77 2.34 7.50 2.40 7.33 2.44
20.0 15.0 7.37 1.85 7.14 1.91 6.89 1.96 6.65 2.02 6.51 2.05
23.9 18.3 7.22 1.51 6.99 1.55 6.76 1.60 6.52 1.64 6.38 1.67
- 231 -
6-3. Heating capacity 6. Capacity table
