Fujitsu AS* G09LECB User Manual

 Indoor units: 9,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 15.92 2.52 15.41 2.59 14.89 2.67 14.37 2.74 14.05 2.79
14 12 18.72 2.54 18.13 2.61 17.52 2.69 16.90 2.76 16.53 2.81
23 19 20.73 2.54 20.08 2.61 19.40 2.69 18.72 2.76 18.31 2.81
32 28 23.36 2.51 22.62 2.58 21.86 2.65 21.09 2.73 20.63 2.77
41 37 26.15 2.48 25.33 2.55 24.47 2.62 23.62 2.70 23.10 2.74
47 43 27.89 2.58 27.01 2.65 26.10 2.73 25.19 2.81 24.63 2.85
50 47 28.86 2.55 27.95 2.63 27.01 2.70 26.06 2.78 25.49 2.82
59 50 29.06 2.12 28.14 2.18 27.19 2.24 26.24 2.30 25.66 2.34
68 59 25.42 1.78 24.62 1.83 23.78 1.88 22.95 1.94 22.45 1.97
75 65 25.69 1.66 24.88 1.71 24.04 1.76 23.20 1.81 22.69 1.84
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.66 2.52 4.52 2.59 4.36 2.67 4.21 2.74 4.12 2.79
-10.0 -11.1 5.49 2.54 5.31 2.61 5.13 2.69 4.95 2.76 4.85 2.81
-5.0 -7.2 6.08 2.54 5.88 2.61 5.69 2.69 5.49 2.76 5.37 2.81
0.0 -2.2 6.85 2.51 6.63 2.58 6.41 2.65 6.18 2.73 6.05 2.77
5.0 2.8 7.67 2.48 7.42 2.55 7.17 2.62 6.92 2.70 6.77 2.74
8.3 6.1 8.18 2.58 7.92 2.65 7.65 2.73 7.38 2.81 7.22 2.85
10.0 8.3 8.46 2.55 8.19 2.63 7.92 2.70 7.64 2.78 7.47 2.82
15.0 10.0 8.52 2.12 8.25 2.18 7.97 2.24 7.69 2.30 7.52 2.34
20.0 15.0 7.45 1.78 7.21 1.83 6.97 1.88 6.73 1.94 6.58 1.97
23.9 18.3 7.53 1.66 7.29 1.71 7.05 1.76 6.80 1.81 6.65 1.84
 Indoor units: 9,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.54 2.52 16.02 2.59 15.48 2.67 14.94 2.74 14.61 2.79
14 12 19.42 2.54 18.81 2.61 18.17 2.69 17.54 2.76 17.15 2.81
23 19 22.01 2.54 21.31 2.61 20.59 2.69 19.87 2.76 19.43 2.81
32 28 24.78 2.47 24.00 2.54 23.19 2.61 22.38 2.68 21.88 2.73
41 37 27.69 2.53 26.82 2.60 25.91 2.68 25.00 2.75 24.45 2.80
47 43 29.44 2.67 28.51 2.75 27.55 2.83 26.59 2.91 26.00 2.96
50 47 30.63 2.28 29.66 2.35 28.66 2.42 27.65 2.48 27.04 2.53
59 50 30.50 2.12 29.54 2.18 28.54 2.24 27.54 2.31 26.93 2.34
68 59 29.56 1.78 28.63 1.83 27.66 1.89 26.69 1.94 26.10 1.97
75 65 27.86 1.71 26.98 1.76 26.07 1.81 25.15 1.86 24.60 1.89
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.85 2.52 4.70 2.59 4.54 2.67 4.38 2.74 4.28 2.79
-10.0 -11.1 5.69 2.54 5.51 2.61 5.33 2.69 5.14 2.76 5.03 2.81
-5.0 -7.2 6.45 2.54 6.25 2.61 6.03 2.69 5.82 2.76 5.70 2.81
0.0 -2.2 7.26 2.47 7.03 2.54 6.80 2.61 6.56 2.68 6.41 2.73
5.0 2.8 8.12 2.53 7.86 2.60 7.59 2.68 7.33 2.75 7.17 2.80
8.3 6.1 8.63 2.67 8.36 2.75 8.07 2.83 7.79 2.91 7.62 2.96
10.0 8.3 8.98 2.28 8.69 2.35 8.40 2.42 8.10 2.48 7.93 2.53
15.0 10.0 8.94 2.12 8.66 2.18 8.36 2.24 8.07 2.31 7.89 2.34
20.0 15.0 8.66 1.78 8.39 1.83 8.11 1.89 7.82 1.94 7.65 1.97
23.9 18.3 8.17 1.71 7.91 1.76 7.64 1.81 7.37 1.86 7.21 1.89
- 232 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu AS* G09LECB Specifications
