 Indoor units: 12,000 Btu + 12,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 26.04 3.61 25.42 3.68 24.80 3.76 24.18 3.83 23.56 3.91
14 12 31.70 3.66 30.94 3.74 30.19 3.81 29.43 3.89 28.68 3.96
23 19 36.58 3.71 35.71 3.79 34.84 3.87 33.97 3.94 33.10 4.02
32 28 38.90 3.50 37.98 3.57 37.05 3.64 36.12 3.72 35.20 3.79
41 37 40.78 3.46 39.81 3.53 38.84 3.61 37.86 3.68 36.89 3.75
47 43 43.05 3.64 42.03 3.71 41.00 3.79 39.98 3.87 38.95 3.94
50 47 43.75 3.63 42.71 3.70 41.67 3.78 40.63 3.85 39.59 3.93
59 50 45.86 3.59 44.77 3.67 43.68 3.74 42.59 3.82 41.49 3.89
68 59 46.63 3.10 45.52 3.16 44.41 3.23 43.30 3.29 42.19 3.36
75 65 49.22 3.08 48.05 3.15 46.88 3.21 45.71 3.28 44.54 3.34
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.63 3.61 7.45 3.68 7.27 3.76 7.09 3.83 6.91 3.91
-10.0 -11.1 9.29 3.66 9.07 3.74 8.85 3.81 8.63 3.89 8.41 3.96
-5.0 -7.2 10.72 3.71 10.47 3.79 10.21 3.87 9.96 3.94 9.70 4.02
0.0 -2.2 11.40 3.50 11.13 3.57 10.86 3.64 10.59 3.72 10.32 3.79
5.0 2.8 11.95 3.46 11.67 3.53 11.38 3.61 11.10 3.68 10.81 3.75
8.3 6.1 12.62 3.64 12.32 3.71 12.02 3.79 11.72 3.87 11.42 3.94
10.0 8.3 12.82 3.63 12.52 3.70 12.21 3.78 11.91 3.85 11.60 3.93
15.0 10.0 13.44 3.59 13.12 3.67 12.80 3.74 12.48 3.82 12.16 3.89
20.0 15.0 13.67 3.10 13.34 3.16 13.01 3.23 12.69 3.29 12.36 3.36
23.9 18.3 14.43 3.08 14.08 3.15 13.74 3.21 13.40 3.28 13.05 3.34
 Indoor units: 7,000 Btu + 7,000 Btu + 7,000 Btu + 7,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 22.36 3.04 21.83 3.10 21.29 3.16 20.76 3.23 20.23 3.29
14 12 27.21 3.08 26.56 3.14 25.92 3.21 25.27 3.27 24.62 3.34
23 19 31.41 3.12 30.66 3.19 29.91 3.25 29.17 3.32 28.42 3.38
32 28 33.40 2.94 32.60 3.01 31.81 3.07 31.01 3.13 30.22 3.19
41 37 35.01 2.91 34.17 2.97 33.34 3.04 32.51 3.10 31.67 3.16
47 43 36.96 3.06 36.08 3.13 35.20 3.19 34.32 3.25 33.44 3.32
50 47 37.56 3.05 36.67 3.12 35.77 3.18 34.88 3.24 33.99 3.31
59 50 39.37 3.02 38.44 3.09 37.50 3.15 36.56 3.21 35.62 3.28
68 59 40.03 2.61 39.08 2.66 38.12 2.72 37.17 2.77 36.22 2.83
75 65 42.26 2.60 41.25 2.65 40.25 2.70 39.24 2.76 38.24 2.81
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 6.55 3.04 6.40 3.10 6.24 3.16 6.08 3.23 5.93 3.29
-10.0 -11.1 7.98 3.08 7.79 3.14 7.60 3.21 7.41 3.27 7.22 3.34
-5.0 -7.2 9.21 3.12 8.99 3.19 8.77 3.25 8.55 3.32 8.33 3.38
0.0 -2.2 9.79 2.94 9.56 3.01 9.32 3.07 9.09 3.13 8.86 3.19
5.0 2.8 10.26 2.91 10.02 2.97 9.77 3.04 9.53 3.10 9.28 3.16
8.3 6.1 10.83 3.06 10.57 3.13 10.32 3.19 10.06 3.25 9.80 3.32
10.0 8.3 11.01 3.05 10.75 3.12 10.49 3.18 10.22 3.24 9.96 3.31
15.0 10.0 11.54 3.02 11.27 3.09 10.99 3.15 10.72 3.21 10.44 3.28
20.0 15.0 11.73 2.61 11.45 2.66 11.17 2.72 10.89 2.77 10.61 2.83
23.9 18.3 12.39 2.60 12.09 2.65 11.80 2.70 11.50 2.76 11.21 2.81
- 291 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu AS* G09LECB Specifications
