Fujitsu AS* G09LECB User Manual

 Indoor units: 7,000 Btu + 7,000 Btu + 7,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 23.95 3.25 23.38 3.32 22.81 3.39 22.24 3.46 21.67 3.53
14 12 29.15 3.30 28.45 3.37 27.76 3.44 27.06 3.51 26.37 3.58
23 19 33.64 3.35 32.84 3.42 32.04 3.49 31.24 3.56 30.44 3.63
32 28 35.77 3.16 34.92 3.22 34.07 3.29 33.22 3.35 32.36 3.42
41 37 37.49 3.12 36.60 3.19 35.71 3.25 34.82 3.32 33.92 3.38
47 43 39.59 3.28 38.64 3.35 37.70 3.42 36.76 3.49 35.82 3.56
50 47 40.23 3.27 39.27 3.34 38.32 3.41 37.36 3.48 36.40 3.55
59 50 42.17 3.24 41.17 3.31 40.16 3.38 39.16 3.44 38.15 3.51
68 59 42.87 2.80 41.85 2.85 40.83 2.91 39.81 2.97 38.79 3.03
75 65 45.26 2.78 44.18 2.84 43.11 2.90 42.03 2.96 40.95 3.02
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.02 3.25 6.85 3.32 6.68 3.39 6.52 3.46 6.35 3.53
-10.0 -11.1 8.54 3.30 8.34 3.37 8.14 3.44 7.93 3.51 7.73 3.58
-5.0 -7.2 9.86 3.35 9.62 3.42 9.39 3.49 9.15 3.56 8.92 3.63
0.0 -2.2 10.48 3.16 10.23 3.22 9.98 3.29 9.74 3.35 9.49 3.42
5.0 2.8 10.99 3.12 10.73 3.19 10.47 3.25 10.20 3.32 9.94 3.38
8.3 6.1 11.60 3.28 11.33 3.35 11.05 3.42 10.77 3.49 10.50 3.56
10.0 8.3 11.79 3.27 11.51 3.34 11.23 3.41 10.95 3.48 10.67 3.55
15.0 10.0 12.36 3.24 12.07 3.31 11.77 3.38 11.48 3.44 11.18 3.51
20.0 15.0 12.57 2.80 12.27 2.85 11.97 2.91 11.67 2.97 11.37 3.03
23.9 18.3 13.27 2.78 12.95 2.84 12.63 2.90 12.32 2.96 12.00 3.02
 Indoor units: 7,000 Btu + 7,000 Btu + 7,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 25.34 3.48 24.74 3.56 24.14 3.63 23.53 3.70 22.93 3.77
14 12 30.85 3.53 30.11 3.61 29.38 3.68 28.64 3.75 27.91 3.83
23 19 35.60 3.58 34.76 3.66 33.91 3.73 33.06 3.81 32.21 3.88
32 28 37.86 3.38 36.96 3.45 36.06 3.52 35.16 3.59 34.25 3.66
41 37 39.68 3.34 38.74 3.41 37.79 3.48 36.85 3.55 35.90 3.62
47 43 41.90 3.51 40.90 3.59 39.90 3.66 38.90 3.73 37.91 3.81
50 47 42.58 3.50 41.57 3.58 40.55 3.65 39.54 3.72 38.52 3.79
59 50 44.63 3.47 43.57 3.54 42.51 3.61 41.44 3.69 40.38 3.76
68 59 45.37 2.99 44.29 3.05 43.21 3.12 42.13 3.18 41.05 3.24
75 65 47.90 2.98 46.76 3.04 45.62 3.10 44.48 3.16 43.34 3.23
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.43 3.48 7.25 3.56 7.07 3.63 6.90 3.70 6.72 3.77
-10.0 -11.1 9.04 3.53 8.83 3.61 8.61 3.68 8.39 3.75 8.18 3.83
-5.0 -7.2 10.43 3.58 10.19 3.66 9.94 3.73 9.69 3.81 9.44 3.88
0.0 -2.2 11.10 3.38 10.83 3.45 10.57 3.52 10.30 3.59 10.04 3.66
5.0 2.8 11.63 3.34 11.35 3.41 11.08 3.48 10.80 3.55 10.52 3.62
8.3 6.1 12.28 3.51 11.99 3.59 11.69 3.66 11.40 3.73 11.11 3.81
10.0 8.3 12.48 3.50 12.18 3.58 11.89 3.65 11.59 3.72 11.29 3.79
15.0 10.0 13.08 3.47 12.77 3.54 12.46 3.61 12.15 3.69 11.84 3.76
20.0 15.0 13.30 2.99 12.98 3.05 12.67 3.12 12.35 3.18 12.03 3.24
23.9 18.3 14.04 2.98 13.71 3.04 13.37 3.10 13.04 3.16 12.70 3.23
- 292 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu AS* G09LECB Specifications

General

Brand	Fujitsu
Model	AS* G09LECB
Category	Air Conditioner
Language	English
