Fujitsu AS* G09LECB User Manual

 Indoor units: 7,000 Btu + 7,000 Btu + 9,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 25.03 3.41 24.43 3.48 23.84 3.55 23.24 3.62 22.64 3.69
14 12 30.46 3.46 29.73 3.53 29.01 3.60 28.28 3.67 27.56 3.74
23 19 35.16 3.51 34.32 3.58 33.48 3.65 32.65 3.72 31.81 3.80
32 28 37.38 3.30 36.49 3.37 35.60 3.44 34.71 3.51 33.82 3.58
41 37 39.19 3.27 38.25 3.34 37.32 3.41 36.39 3.47 35.45 3.54
47 43 41.37 3.44 40.39 3.51 39.40 3.58 38.42 3.65 37.43 3.72
50 47 42.05 3.43 41.04 3.50 40.04 3.57 39.04 3.64 38.04 3.71
59 50 44.07 3.39 43.02 3.46 41.97 3.54 40.92 3.61 39.88 3.68
68 59 44.81 2.93 43.74 2.99 42.67 3.05 41.61 3.11 40.54 3.17
75 65 47.30 2.91 46.18 2.97 45.05 3.03 43.92 3.10 42.80 3.16
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.33 3.41 7.16 3.48 6.99 3.55 6.81 3.62 6.64 3.69
-10.0 -11.1 8.93 3.46 8.71 3.53 8.50 3.60 8.29 3.67 8.08 3.74
-5.0 -7.2 10.30 3.51 10.06 3.58 9.81 3.65 9.57 3.72 9.32 3.80
0.0 -2.2 10.96 3.30 10.70 3.37 10.44 3.44 10.17 3.51 9.91 3.58
5.0 2.8 11.48 3.27 11.21 3.34 10.94 3.41 10.66 3.47 10.39 3.54
8.3 6.1 12.12 3.44 11.84 3.51 11.55 3.58 11.26 3.65 10.97 3.72
10.0 8.3 12.32 3.43 12.03 3.50 11.74 3.57 11.44 3.64 11.15 3.71
15.0 10.0 12.92 3.39 12.61 3.46 12.30 3.54 11.99 3.61 11.69 3.68
20.0 15.0 13.13 2.93 12.82 2.99 12.51 3.05 12.19 3.11 11.88 3.17
23.9 18.3 13.86 2.91 13.53 2.97 13.20 3.03 12.87 3.10 12.54 3.16
 Indoor units: 7,000 Btu + 7,000 Btu + 9,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 26.42 3.63 25.80 3.70 25.17 3.78 24.54 3.85 23.91 3.93
14 12 32.16 3.68 31.39 3.75 30.63 3.83 29.86 3.91 29.10 3.98
23 19 37.12 3.73 36.24 3.81 35.35 3.89 34.47 3.96 33.58 4.04
32 28 39.47 3.52 38.53 3.59 37.59 3.66 36.65 3.74 35.71 3.81
41 37 41.37 3.48 40.39 3.55 39.40 3.63 38.42 3.70 37.43 3.77
47 43 43.68 3.66 42.64 3.73 41.60 3.81 40.56 3.89 39.52 3.96
50 47 44.39 3.65 43.34 3.72 42.28 3.80 41.22 3.87 40.17 3.95
59 50 46.53 3.61 45.43 3.69 44.32 3.76 43.21 3.84 42.10 3.91
68 59 47.31 3.11 46.18 3.18 45.06 3.24 43.93 3.31 42.80 3.37
75 65 49.94 3.10 48.75 3.17 47.57 3.23 46.38 3.29 45.19 3.36
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.74 3.63 7.56 3.70 7.38 3.78 7.19 3.85 7.01 3.93
-10.0 -11.1 9.43 3.68 9.20 3.75 8.98 3.83 8.75 3.91 8.53 3.98
-5.0 -7.2 10.88 3.73 10.62 3.81 10.36 3.89 10.10 3.96 9.84 4.04
0.0 -2.2 11.57 3.52 11.29 3.59 11.02 3.66 10.74 3.74 10.47 3.81
5.0 2.8 12.13 3.48 11.84 3.55 11.55 3.63 11.26 3.70 10.97 3.77
8.3 6.1 12.80 3.66 12.50 3.73 12.19 3.81 11.89 3.89 11.58 3.96
10.0 8.3 13.01 3.65 12.70 3.72 12.39 3.80 12.08 3.87 11.77 3.95
15.0 10.0 13.64 3.61 13.31 3.69 12.99 3.76 12.66 3.84 12.34 3.91
20.0 15.0 13.87 3.11 13.54 3.18 13.20 3.24 12.87 3.31 12.54 3.37
23.9 18.3 14.64 3.10 14.29 3.17 13.94 3.23 13.59 3.29 13.24 3.36
- 294 -
6-3. Heating capacity 6. Capacity table
