Fujitsu AS* G09LECB User Manual

 Indoor units: 7,000 Btu + 7,000 Btu + 9,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 26.68 3.52 26.04 3.59 25.41 3.67 24.77 3.74 24.14 3.81
14 12 32.47 3.57 31.70 3.65 30.92 3.72 30.15 3.80 29.38 3.87
23 19 37.48 3.62 36.58 3.70 35.69 3.77 34.80 3.85 33.91 3.93
32 28 39.85 3.42 38.90 3.49 37.95 3.56 37.01 3.63 36.06 3.70
41 37 41.77 3.38 40.78 3.45 39.78 3.52 38.79 3.59 37.79 3.66
47 43 44.10 3.55 43.05 3.63 42.00 3.70 40.95 3.77 39.90 3.85
50 47 44.82 3.54 43.75 3.61 42.69 3.69 41.62 3.76 40.55 3.84
59 50 46.98 3.51 45.86 3.58 44.74 3.65 43.63 3.73 42.51 3.80
68 59 47.76 3.02 46.63 3.09 45.49 3.15 44.35 3.21 43.21 3.28
75 65 50.42 3.01 49.22 3.07 48.02 3.14 46.82 3.20 45.62 3.26
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.82 3.52 7.63 3.59 7.45 3.67 7.26 3.74 7.07 3.81
-10.0 -11.1 9.52 3.57 9.29 3.65 9.06 3.72 8.84 3.80 8.61 3.87
-5.0 -7.2 10.98 3.62 10.72 3.70 10.46 3.77 10.20 3.85 9.94 3.93
0.0 -2.2 11.68 3.42 11.40 3.49 11.12 3.56 10.85 3.63 10.57 3.70
5.0 2.8 12.24 3.38 11.95 3.45 11.66 3.52 11.37 3.59 11.08 3.66
8.3 6.1 12.92 3.55 12.62 3.63 12.31 3.70 12.00 3.77 11.69 3.85
10.0 8.3 13.14 3.54 12.82 3.61 12.51 3.69 12.20 3.76 11.89 3.84
15.0 10.0 13.77 3.51 13.44 3.58 13.11 3.65 12.79 3.73 12.46 3.80
20.0 15.0 14.00 3.02 13.67 3.09 13.33 3.15 13.00 3.21 12.67 3.28
23.9 18.3 14.78 3.01 14.43 3.07 14.07 3.14 13.72 3.20 13.37 3.26
 Indoor units: 7,000 Btu + 7,000 Btu + 12,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 26.68 3.66 26.04 3.74 25.41 3.82 24.77 3.89 24.14 3.97
14 12 32.47 3.72 31.70 3.79 30.92 3.87 30.15 3.95 29.38 4.03
23 19 37.48 3.77 36.58 3.85 35.69 3.93 34.80 4.01 33.91 4.08
32 28 39.85 3.55 38.90 3.63 37.95 3.70 37.01 3.78 36.06 3.85
41 37 41.77 3.52 40.78 3.59 39.78 3.66 38.79 3.74 37.79 3.81
47 43 44.10 3.70 43.05 3.77 42.00 3.85 40.95 3.93 39.90 4.00
50 47 44.82 3.68 43.75 3.76 42.69 3.84 41.62 3.92 40.55 3.99
59 50 46.98 3.65 45.86 3.73 44.74 3.80 43.63 3.88 42.51 3.95
68 59 47.76 3.15 46.63 3.21 45.49 3.28 44.35 3.34 43.21 3.41
75 65 50.42 3.13 49.22 3.20 48.02 3.26 46.82 3.33 45.62 3.39
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.82 3.66 7.63 3.74 7.45 3.82 7.26 3.89 7.07 3.97
-10.0 -11.1 9.52 3.72 9.29 3.79 9.06 3.87 8.84 3.95 8.61 4.03
-5.0 -7.2 10.98 3.77 10.72 3.85 10.46 3.93 10.20 4.01 9.94 4.08
0.0 -2.2 11.68 3.55 11.40 3.63 11.12 3.70 10.85 3.78 10.57 3.85
5.0 2.8 12.24 3.52 11.95 3.59 11.66 3.66 11.37 3.74 11.08 3.81
8.3 6.1 12.92 3.70 12.62 3.77 12.31 3.85 12.00 3.93 11.69 4.00
10.0 8.3 13.14 3.68 12.82 3.76 12.51 3.84 12.20 3.92 11.89 3.99
15.0 10.0 13.77 3.65 13.44 3.73 13.11 3.80 12.79 3.88 12.46 3.95
20.0 15.0 14.00 3.15 13.67 3.21 13.33 3.28 13.00 3.34 12.67 3.41
23.9 18.3 14.78 3.13 14.43 3.20 14.07 3.26 13.72 3.33 13.37 3.39
- 295 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu AS* G09LECB Specifications
