– 68 –
CLEANING AND CARE
Cleaning the Air Filter
Open the Intake Grille, and remove the
air Filter.
Lift up the air filter's handle, disconnect the two
lower tabs and pull out.
1
When using the optional Air Cleaning
Filter
• Install the optional Air Cleaning Filter set (APS-
03D) as instructed (Instruction Manual are fur-
nished with the Air Cleaning Filter set).
Hooks (two place)
Air filter handle
Remove dust with a vacuum cleaner or
by washing.
After washing, allow to dry thoroughly in a shad-
ed place.
Replace the Air Filter and close the
Intake Grille.
q Align the sides of the Air Filter with the
panel, and push in fully, making sure the
two lower tabs are returned properly to their
holes in the panel.
2
Hooks (two place)
w Close the Intake Grille.
(For purposes of example, the illustration shows
the unit without Intake Grille installed.)
• Dust can cleaned from the Air Filter either with a
vacuum cleaner, or by washing the filter in a
solution of mild detergent and warm water. If you
wash the filter, be sure to allow it to dry thorough-
ly in a shady place before reinstalling.
• If dirt is allowed to accumulate on the Air Filter,
air flow will be reduced, lowering operating effi-
ciency and increasing noise.
• During periods of normal use, the Air Filters
should be cleaned every two weeks.
• When used for extended periods, the unit may
accumulate dirt inside, reducing its perfor-
mance. We recommend that the unit be
inspected regularly, in addition to your own
cleaning and care. For more information, con-
sult authorized service personnel.
• When cleaning the unit's body, do not use
water hotter than 40°C, harsh abrasive
cleansers, or volatile agents like benzene or
thinner.
• Do not expose the unit body to liquid insecti-
cides or hairsprays.
• When shutting down the unit for one month or
more, first allow the fan mode to operate con-
tinuously for about onehalf day to allow internal
parts to dry thoroughly.
To Next Page
