Fujitsu ASU15RLS2 Service Manual

35
34
36
37
32
33
17
31 Evaporator Total Assy 9319327013
32 Joint Pipe Assy 9319322018
33 Joint Pipe Holder 9318901009
35
34
Filter Guide 9318887006
36 Evaporator Holder L 9318875003
Base 9318874006
37 Air Seal 9319295008
Ref. Description Part number
INDOOR UNIT
Evaporator
2012.12.25
31

Fujitsu ASU15RLS2 Specifications

General

Brand	Fujitsu
Model	ASU15RLS2
Category	Air Conditioner
Language	English
