Fujitsu ASU15RLS2 Service Manual

OUTDOOR UNIT
2012.12.25 21
15 Compressor Assy 9318334005
17 3-way Valve Sub Assy 9317109062
20 Pulse Motor Valve Assy 9315587022
19 Solenoid 9970110023
14 Condenser Total Assy 9317089104
21 Expansion Valve Coil 9970095030
18 4-way Valve Assy 9318457018
16 2-way Valve Assy 9317171014
Ref. Description Part number
19
18
13
11
12
20
21
17
16
15
14
12 Heater Holder A 9318631005
13 Heater Holder B 9318651003
11 Heater Unit Assy 9900616014
