Fujitsu ASU18RLF Design & Technical Manual

¢
Parts
Air outlet shutter plate
Model: UTR-YDZB
Insulation kit for high humidity
Model: UTZ-KXGC
For compact cassette type
Insulation
kit
For compact cassette type
Fresh air intake kit
Model: UTZ-VXAA
External control set
Model: UTD-ECS5A
For compact cassette type
(×1) (×2)
(×1) (×2)
For slim duct type
External connect kit
Model: UTY-XWZX
External connect kit
Model: UTY-XWZXZ5
(
x 1
)(
x 1
)
For compact cassette type and
wall mounted type (ASU18RLFand ASU24RLF)
(
x 1
)(
x 2
)
For wall mounted type (ASU7RLF1, ASU9RLF1,
ASU12RLF1, and ASU15RLF1) and floor type
Auto louver grille kit
Remote sensor unit
Model: UTY-XSZX
Models:
UTD-GXSA-W
*1
UTD-GXSB-W
*2
UTD-GXSC-W
*3
UTD-GXTA-W
*1
UTD-GXTB-W
*2
UTD-GXTC-W
*3
*1 For slim duct (7-12 models)
*2 For slim duct (18 model)
*3 For slim duct (24 model)
For slim duct type
Communication kit
Model: UTY-XCBXZ2
Communication kit
Model: UTY-XCBXZ2
For wall mounted type (ASU7RLF, ASU9RLF, and
ASU12RLF)
For wall mounted type (ASU7RLF1, ASU9RLF1,
ASU12RLF1, and ASU15RLF1)
- 169 -
16-3. Others 16. Optional parts
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
