Fujitsu ASU18RLF Design & Technical Manual

14. Optional parts
Exterior Part name Model name Summary
x 4
x 1
Adapter kit
K9FZ1818
(UTP-MU36A2)
For 2rooms combination system
It can exchange liquid pipe size Ø1/4
in (Ø6.35 mm) for Ø3/8 in (Ø9.52
mm), and Ø3/8 in (Ø9.52 mm) for
Ø1/2 in (Ø12.70 mm).
If you choose 2-indoor-units system
"18,000 Btu + 18,000 Btu", then you
need this kit.
14-1. 2 rooms combination (with optional part K9FZ1818)
: Note that the hatching items are different from those of 3 or 4 rooms combination.
¢ Size of piping
Indoor unit B
(18,000 Btu)
Indoor unit
A
(18,000 Btu)
Gas pipe:
Ø1/2 in (Ø12.70 mm)
Outdoor unit
Liquid pipe:
Ø3/8 in (Ø9.52 mm)
- 309 -
14-1. 2 rooms combination (with optional part K9FZ1818) 14. Optional parts
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1
