Fujitsu ASU18RLF Design & Technical Manual

6-3. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOU36RLXFZ1
• TC: Total Capacity, IP: Input Power
• The data is based on the following conditions:
Pipe length: 7.5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
 Indoor units: 7,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 7.26 1.21 7.08 1.24 6.91 1.26 6.74 1.29 6.56 1.31
14 12 8.83 1.23 8.62 1.26 8.41 1.28 8.20 1.31 7.99 1.33
23 19 10.19 1.25 9.95 1.27 9.71 1.30 9.46 1.33 9.22 1.35
32 28 10.84 1.18 10.58 1.20 10.32 1.23 10.06 1.25 9.81 1.28
41 37 11.36 1.16 11.09 1.19 10.82 1.21 10.55 1.24 10.28 1.26
47 43 11.99 1.22 11.71 1.25 11.42 1.28 11.14 1.30 10.85 1.33
50 47 12.19 1.22 11.90 1.25 11.61 1.27 11.32 1.30 11.03 1.32
59 50 12.78 1.21 12.47 1.23 12.17 1.26 11.86 1.28 11.56 1.31
68 59 12.99 1.04 12.68 1.06 12.37 1.09 12.06 1.11 11.75 1.13
75 65 13.71 1.04 13.39 1.06 13.06 1.08 12.73 1.10 12.41 1.12
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 2.13 1.21 2.08 1.24 2.03 1.26 1.97 1.29 1.92 1.31
-10.0 -11.1 2.59 1.23 2.53 1.26 2.46 1.28 2.40 1.31 2.34 1.33
-5.0 -7.2 2.99 1.25 2.92 1.27 2.84 1.30 2.77 1.33 2.70 1.35
0.0 -2.2 3.18 1.18 3.10 1.20 3.03 1.23 2.95 1.25 2.87 1.28
5.0 2.8 3.33 1.16 3.25 1.19 3.17 1.21 3.09 1.24 3.01 1.26
8.3 6.1 3.52 1.22 3.43 1.25 3.35 1.28 3.26 1.30 3.18 1.33
10.0 8.3 3.57 1.22 3.49 1.25 3.40 1.27 3.32 1.30 3.23 1.32
15.0 10.0 3.74 1.21 3.66 1.23 3.57 1.26 3.48 1.28 3.39 1.31
20.0 15.0 3.81 1.04 3.72 1.06 3.63 1.09 3.54 1.11 3.44 1.13
23.9 18.3 4.02 1.04 3.92 1.06 3.83 1.08 3.73 1.10 3.64 1.12
