Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 7,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 13.01 1.82 12.60 1.88 12.18 1.93 11.75 1.99 11.49 2.02
14 12 14.68 1.94 14.22 1.99 13.74 2.05 13.26 2.11 12.97 2.14
23 19 16.52 1.90 16.00 1.95 15.46 2.01 14.92 2.07 14.59 2.10
32 28 18.62 1.84 18.04 1.90 17.43 1.95 16.82 2.01 16.45 2.04
41 37 20.74 1.79 20.09 1.84 19.41 1.89 18.73 1.95 18.32 1.98
47 43 22.12 1.86 21.42 1.91 20.70 1.97 19.98 2.03 19.54 2.06
50 47 22.29 1.88 21.58 1.93 20.85 1.99 20.12 2.05 19.68 2.08
59 50 22.51 1.90 21.80 1.95 21.06 2.01 20.32 2.07 19.88 2.10
68 59 22.07 1.66 21.37 1.71 20.65 1.76 19.93 1.80 19.49 1.83
75 65 20.19 1.11 19.55 1.14 18.89 1.17 18.23 1.20 17.83 1.22
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 3.81 1.82 3.69 1.88 3.57 1.93 3.44 1.99 3.37 2.02
-10.0 -11.1 4.30 1.94 4.17 1.99 4.03 2.05 3.89 2.11 3.80 2.14
-5.0 -7.2 4.84 1.90 4.69 1.95 4.53 2.01 4.37 2.07 4.28 2.10
0.0 -2.2 5.46 1.84 5.29 1.90 5.11 1.95 4.93 2.01 4.82 2.04
5.0 2.8 6.08 1.79 5.89 1.84 5.69 1.89 5.49 1.95 5.37 1.98
8.3 6.1 6.48 1.86 6.28 1.91 6.07 1.97 5.85 2.03 5.73 2.06
10.0 8.3 6.53 1.88 6.33 1.93 6.11 1.99 5.90 2.05 5.77 2.08
15.0 10.0 6.60 1.90 6.39 1.95 6.17 2.01 5.96 2.07 5.83 2.10
20.0 15.0 6.47 1.66 6.26 1.71 6.05 1.76 5.84 1.80 5.71 1.83
23.9 18.3 5.92 1.11 5.73 1.14 5.54 1.17 5.34 1.20 5.22 1.22
 Indoor units: 7,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 13.25 1.77 12.84 1.82 12.40 1.88 11.97 1.93 11.70 1.96
14 12 15.05 1.79 14.58 1.84 14.09 1.89 13.59 1.94 13.29 1.98
23 19 16.93 1.79 16.39 1.84 15.84 1.89 15.28 1.94 14.95 1.98
32 28 19.38 1.77 18.77 1.82 18.13 1.87 17.50 1.92 17.11 1.95
41 37 21.95 1.74 21.25 1.79 20.53 1.84 19.82 1.90 19.38 1.93
47 43 23.41 1.81 22.67 1.87 21.90 1.92 21.13 1.97 20.67 2.01
50 47 23.58 1.79 22.84 1.84 22.06 1.89 21.29 1.94 20.82 1.98
59 50 23.81 1.79 23.06 1.84 22.28 1.89 21.50 1.94 21.03 1.98
68 59 23.35 1.62 22.61 1.66 21.84 1.71 21.08 1.76 20.62 1.79
75 65 23.64 1.08 22.89 1.11 22.12 1.14 21.34 1.17 20.87 1.19
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 3.88 1.77 3.76 1.82 3.63 1.88 3.51 1.93 3.43 1.96
-10.0 -11.1 4.41 1.79 4.27 1.84 4.13 1.89 3.98 1.94 3.90 1.98
-5.0 -7.2 4.96 1.79 4.80 1.84 4.64 1.89 4.48 1.94 4.38 1.98
0.0 -2.2 5.68 1.77 5.50 1.82 5.31 1.87 5.13 1.92 5.02 1.95
5.0 2.8 6.43 1.74 6.23 1.79 6.02 1.84 5.81 1.90 5.68 1.93
8.3 6.1 6.86 1.81 6.64 1.87 6.42 1.92 6.19 1.97 6.06 2.01
10.0 8.3 6.91 1.79 6.69 1.84 6.47 1.89 6.24 1.94 6.10 1.98
15.0 10.0 6.98 1.79 6.76 1.84 6.53 1.89 6.30 1.94 6.16 1.98
20.0 15.0 6.84 1.62 6.63 1.66 6.40 1.71 6.18 1.76 6.04 1.79
23.9 18.3 6.93 1.08 6.71 1.11 6.48 1.14 6.26 1.17 6.12 1.19
- 192 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU18RLXFZ OUTDOOR UNIT AOU18RLXFZ

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
