• Standard type grille (UTG-CCGF)
27-9/16 (700)
27-9/16 (700)
Bottom view
1-3/16 (30) 1-15/16 (49)
Side view
• Grid type grille (UTG-CCGFG)
24-7/16 (620)
24-7/16 (620)
Bottom view
Side view
1-3/16 (30)
1-15/16 (49)
- 14 -
3-1. Compact cassette type 3. Dimensions
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
