2. Dimensions
2-1. Models: ASYG07KGTA, ASYG09KGTA, ASYG12KGTA,
and ASYG14KGTA
Unit: mm
834
(834)
Outline of indoor unit
327
273
273 54
215
3.0
270(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
DESIGN & TECHNICAL MANUAL
- 4 -
WALL MOUNTED
ASYG07-14KGTA
