Item no. Part no. Part name Service part
50 9387587227 Base assy ♦
51 9388139012 Pipe bracket A ♦
52 9334143001 Under cover C ♦
53 9334137000 Screw cover ♦
54 9383765056 WLAN adapter holder assy ♦
55 9384563040 WLAN adapter ♦
56
9711732743 Main PCB (07 model) ♦
9711732750 Main PCB (09 model) ♦
9711732767 Main PCB (12 model) ♦
9711732774 Main PCB (14 model) ♦
57 9387488029 Cable guide ♦
58 9901013010 Terminal 3P ♦
59 9383729041 Wire cover assy ♦
60 9711146021 Display assy ♦
61 9711147028 Indicator PCB ♦
62
9603688028 DC fan motor (07—12 models) ♦
9603492021 DC fan motor (14 model) ♦
63 9387589047 Motor case assy ♦
64 9317250009 Air clean filter assy ♦
65 9332911008 Electric filter holder ♦
66
9387593211 Evaporator total assy (07—12 models) ♦
9387593204 Evaporator total assy (14 model) ♦
67 9900627065 Thermistor assy ♦
68 9387467017 Room thermistor holder ♦
69 9333628004 Bearing D assy ♦
70 9333606033 Crossflow fan assy ♦
— 9901010071
Wire with connector
(CN75 on Main PCB—WLAN adapter)
♦
a — Box shield —
b — Control box —
c — PCB holder A —
d — Control cover —
e — Display case assy —
f — Motor case —
g — Motor cover —
2-1. Models: ASYG07KMCF, ASYG09KMCF, ASYG12KMCF, and ASYG14KMCF - (02-5) - 2. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
