Item no. Part no. Part name Service part
1 9322556165 Top panel assy ♦
2
9709687079 Main PCB (for 07 model) ♦
9709687093 Main PCB (for 09 model) ♦
9709687116 Main PCB (for 12 model) ♦
3 9900727062 Thermistor assy ♦
4 9900565053 Thermistor assy (outdoor temp) ♦
5 9901012013 Reactor assy ♦
6 9333787008 Heat sink ♦
7 9322552112 Cabinet right assy ♦
8 9322570000 Switch cover assy ♦
9 9322144003 Drain pipe ♦
10 9323501003 Base assy ♦
11 9322555328 Front panel assy ♦
12 9387859003 Emblem ♦
13 9322135001 Blow grille ♦
14 9322136008 Propeller fan ♦
15 9603553005 Brushless motor ♦
16
9322553089 Motor bracket assy (for 07-09 model) ♦
9322553096 Motor bracket assy (for 12 model) ♦
17
9322272003 Condenser total assy (for 07-09 model) ♦
9322273000 Condenser total assy (for 12 model) ♦
18 9322811059 Protective net assy ♦
a — Inverter assy —
3-1. Models: AOYG07KMCC, AOYG09KMCC, and AOYG12KMCC - (02-7) - 3. Outdoor unit parts list
