Fujitsu ASYG12KETA Design & Technical Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
-5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
0.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
15.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
20.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
25.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
30.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
35.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
40.0 1.62 0.91 1.83 1.03 1.93 1.19 2.07 1.34 2.21 1.46 2.28 1.67
46.0 1.28 0.57 1.45 0.65 1.53 0.75 1.64 0.84 1.75 0.92 1.81 1.05
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
-5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 2.08 1.14 2.35 1.30 2.47 1.50 2.65 1.69 2.83 1.85 2.92 2.11
46.0 1.64 0.72 1.86 0.82 1.96 0.94 2.10 1.06 2.24 1.16 2.31 1.33
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
-5.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
0.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
5.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
10.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
15.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
20.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
25.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
30.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
35.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
40.0 2.79 1.52 3.15 1.73 3.32 1.99 3.56 2.24 3.80 2.45 3.92 2.81
46.0 2.21 0.95 2.50 1.08 2.63 1.25 2.82 1.40 3.01 1.53 3.11 1.76
Model: AUXG14KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
-5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
0.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
15.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
20.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
25.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
30.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
35.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
40.0 3.24 1.67 3.67 1.91 3.87 2.19 4.14 2.47 4.42 2.70 4.56 3.09
46.0 2.57 1.05 2.90 1.20 3.06 1.38 3.28 1.55 3.50 1.69 3.61 1.94
