Page #13 background imageLoading...
Page #13 background image
¢
Model: AOYG14KMCC
Unit: mm
580
109
330
353
Pitch of bolts
for installation
Pitch of bolts for installation
Top view
4-
M1
0 hole
Side viewSide view
Front view
799 68 29016
33 30
19
542
20
Airflow
Bottom view Side view (Valve part)
37
399
Drain port Ø42
184
120
180
2-2. Outdoor unit - (01-7) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
