Fujitsu ASYG12KPCA User Manual

4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ASYG07KPCA
AFR
m
3
/h
580
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 1.84 0.88 1.83 0.90 1.79 0.92 1.75 0.94 1.70 0.96
-10 -11 2.14 0.93 2.09 0.95 2.04 0.97 1.98 0.99 1.93 1.01
-5 -7 2.47 1.01 2.41 1.03 2.36 1.06 2.30 1.08 2.24 1.10
0 -2 2.93 1.15 2.86 1.17 2.79 1.20 2.72 1.22 2.65 1.24
5 3 3.31 1.28 3.31 1.31 3.23 1.33 3.15 1.36 3.06 1.39
7 6 3.47 1.33 3.44 1.36 3.40 1.39 3.32 1.42 3.23 1.45
10 8 3.74 1.38 3.65 1.41 3.56 1.44 3.47 1.47 3.38 1.50
15 10 3.81 1.39 3.72 1.42 3.63 1.45 3.54 1.48 3.45 1.51
20 15 3.68 1.09 3.59 1.12 3.50 1.14 3.41 1.16 3.33 1.18
24 18 3.89 1.09 3.79 1.12 3.70 1.14 3.61 1.16 3.52 1.18
¢
Model: ASYG09KPCA
AFR
m
3
/h
580
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.12 0.88 2.12 0.90 2.09 0.92 2.10 0.94 2.08 0.96
-10 -11 2.53 0.89 2.47 0.91 2.41 0.93 2.34 0.95 2.28 0.96
-5 -7 2.85 0.96 2.78 0.98 2.71 1.00 2.65 1.02 2.58 1.04
0 -2 3.33 1.11 3.25 1.14 3.17 1.16 3.09 1.18 3.01 1.21
5 3 3.80 1.27 3.71 1.30 3.62 1.32 3.53 1.35 3.44 1.38
7 6 3.99 1.33 3.90 1.36 3.80 1.39 3.71 1.42 3.61 1.45
10 8 4.13 1.38 4.03 1.41 3.94 1.44 3.84 1.47 3.74 1.50
15 10 4.16 1.39 4.06 1.42 3.96 1.45 3.86 1.48 3.77 1.51
20 15 3.99 1.09 3.90 1.12 3.80 1.14 3.71 1.16 3.61 1.18
24 18 4.10 1.09 4.00 1.12 3.90 1.14 3.80 1.16 3.71 1.18
¢
Model: ASYG12KPCA
AFR
m
3
/h
630
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.73 1.03 2.67 1.05 2.60 1.07 2.54 1.10 2.47 1.12
-10 -11 2.91 1.08 2.85 1.10 2.78 1.12 2.71 1.14 2.64 1.17
-5 -7 3.31 1.17 3.23 1.19 3.15 1.21 3.08 1.24 3.00 1.26
0 -2 4.03 1.32 3.94 1.35 3.84 1.38 3.74 1.40 3.65 1.43
5 3 4.75 1.47 4.64 1.51 4.53 1.54 4.41 1.57 4.30 1.60
7 6 5.04 1.54 4.92 1.57 4.80 1.60 4.68 1.63 4.56 1.66
10 8 4.61 1.38 4.50 1.41 4.39 1.44 4.28 1.47 4.17 1.50
15 10 4.73 1.39 4.62 1.42 4.50 1.45 4.39 1.48 4.28 1.51
20 15 4.52 1.30 4.41 1.32 4.30 1.35 4.19 1.38 4.09 1.40
24 18 4.62 1.28 4.51 1.30 4.40 1.33 4.29 1.36 4.18 1.38
- 8 -
4-2. Heating capacity 4. Capacity table
WALL MOUNTED ASYG07-12KPCA WALL MOUNTED ASYG07-12KPCA

Fujitsu ASYG12KPCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	No
Product color	White
Gas hose diameter	9.52 mm
Hose length (max)	20 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Dehumidifying capacity	1.8 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (nominal)	3400 W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.3
Seasonal efficiency rating (heating) (SCOP)	4.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	3800 W
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	3.4 kW
Energy efficiency class (cooling)	A++
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Colder heating season)	- kW
Design load (heating) (Warmer heating season)	1.3 kW
Design load (heating) (Average heating season)	2.5 kW
Energy efficiency class (heating) (Average heating season)	A+
Indoor unit type	Wall-mountable
Indoor unit depth	224 mm
Indoor unit width	784 mm
Indoor unit height	270 mm
Indoor unit weight	8000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	630 m³/h
Indoor unit sound power level	59 dB
Indoor unit noise level (low speed)	22 dB
Indoor unit noise level (high speed)	46 dB
Outdoor unit noise level	- dB
