Fujitsu ASYG12LUCA

2. MODEL SELECTION
CAPACITY TABLE (OUTDOOR UNIT)4.
COOLING CAPACITY4-1.
MODEL : AO


G45LBT8
Capacity in kW

Indoor unit
connecting
capacity (%)
Outdoor
temperature
(°C)
Indoor temperature
21.0°CDB 23.0°CDB 27.0°CDB 29.0°CDB 32.0°CDB
15.0°CWB 16.0°CWB 19.0°CWB 21.0°CWB 23.0°CWB
TC IP TC IP TC IP TC IP TC IP
130
-5.0 16.7 2.80 17.5 2.85 18.4 2.90 19.5 2.95 20.6 3.00
0.0 16.7 2.90 17.5 3.00 18.4 3.05 19.5 3.10 20.6 3.15
5.0 16.7 2.95 17.5 3.05 18.4 3.10 19.5 3.15 20.6 3.20
10.0 16.7 3.10 17.5 3.25 18.4 3.30 19.5 3.35 20.6 3.40
15.0 16.7 3.40 17.5 3.55 18.4 3.60 19.5 3.65 20.6 3.70
20.0 16.7 4.25 17.5 4.35 18.4 4.45 19.5 4.45 20.0 4.50
25.0 15.8 4.80 16.5 5.15 18.0 5.20 19.0 5.20 19.5 5.25
30.0 14.5 5.11 15.7 5.49 16.6 5.55 18.3 5.61 18.8 5.68
35.0 13.6 5.40 14.3 5.85 15.7 5.87 16.6 5.93 17.0 5.98
40.0 12.3 5.50 13.0 5.90 14.0 5.96 14.5 5.98 15.0 5.98
46.0 11.0 5.01 12.0 5.06 12.3 5.15 13.1 5.20 13.5 5.30
120
-5.0 15.6 2.50 16.5 2.55 17.5 2.65 19.0 2.75 20.1 2.80
0.0 15.6 2.56 16.5 2.75 17.5 2.80 19.0 2.90 20.1 2.95
5.0 15.6 2.61 16.5 2.85 17.5 2.90 19.0 3.05 20.1 3.10
10.0 15.6 2.70 16.5 2.95 17.5 3.05 19.0 3.05 20.1 3.20
15.0 15.6 2.90 16.5 3.20 17.5 3.30 19.0 3.35 20.1 3.40
20.0 15.6 3.55 16.5 3.60 17.5 4.00 19.0 4.05 20.1 4.10
25.0 14.9 4.20 16.0 4.40 17.0 4.70 18.6 4.80 19.1 4.85
30.0 14.0 4.76 15.1 5.13 16.2 5.33 18.0 5.45 18.5 5.51
35.0 13.2 5.24 14.1 5.79 15.6 5.90 16.2 5.93 16.7 5.96
40.0 12.2 5.20 12.9 5.90 13.8 5.96 14.4 5.98 15.7 5.98
46.0 10.8 4.94 11.7 5.06 12.1 5.15 12.9 5.20 13.3 5.28
110
-5.0 14.4 2.25 15.5 2.30 16.6 2.45 18.0 2.60 19.6 2.65
0.0 14.4 2.29 15.5 2.35 16.6 2.55 18.0 2.65 19.6 2.75
5.0 14.4 2.44 15.5 2.60 16.6 2.65 18.0 2.75 19.6 2.80
10.0 14.4 2.51 15.5 2.65 16.6 2.80 18.0 2.85 19.6 3.00
15.0 14.4 2.60 15.5 2.85 16.6 3.05 18.0 3.15 19.6 3.20
20.0 14.4 2.95 15.5 3.20 16.6 3.55 18.0 3.65 19.6 3.75
25.0 13.9 3.50 15.1 3.75 16.3 4.20 17.8 4.40 18.9 4.45
30.0 13.2 4.30 14.5 4.63 15.8 5.11 17.6 5.22 18.1 5.29
35.0 12.7 5.05 13.9 5.33 15.5 5.90 15.9 5.93 16.7 5.96
40.0 11.7 5.00 12.7 5.90 13.5 5.96 14.3 5.98 15.4 5.98
46.0 10.6 4.82 11.4 5.01 11.8 5.11 12.7 5.18 13.1 5.26
100
-5.0 13.2 2.00 14.5 2.11 15.6 2.25 17.5 2.40 19.0 2.50
0.0 13.2 2.08 14.5 2.14 15.6 2.30 17.5 2.45 19.0 2.55
5.0 13.2 2.12 14.5 2.19 15.6 2.40 17.5 2.50 19.0 2.65
10.0 13.2 2.16 14.5 2.25 15.6 2.50 17.5 2.60 19.0 2.80
15.0 13.2 2.21 14.5 2.40 15.6 2.75 17.5 2.80 19.0 3.00
20.0 12.9 2.45 14.4 2.63 15.5 3.00 17.4 3.10 19.0 3.20
25.0 12.6 2.80 14.2 3.20 15.3 3.50 17.2 3.90 18.4 4.00
30.0 12.2 3.81 13.9 4.15 15.2 4.41 17.0 4.70 17.7 5.00
35.0 11.7 4.67 13.5 4.95 14.0 5.20 15.6 5.26 16.0 5.34
40.0 11.2 5.01 12.5 5.12 13.0 5.21 14.2 5.32 15.0 5.41
46.0 10.4 4.75 11.0 4.97 11.5 5.05 12.5 5.10 12.9 5.15
90
-5.0 12.0 1.80 13.5 1.95 14.2 2.20 16.0 2.35 17.5 2.45
0.0 12.0 1.86 13.5 2.05 14.2 2.25 16.0 2.40 17.5 2.50
5.0 12.0 1.94 13.5 2.10 14.2 2.35 16.0 2.45 17.5 2.60
10.0 12.0 2.01 13.5 2.20 14.2 2.45 16.0 2.55 17.5 2.75
15.0 12.0 2.10 13.5 2.35 14.2 2.70 16.0 2.75 17.5 2.95
20.0 12.0 2.38 13.5 2.45 14.2 2.95 16.0 3.05 17.5 3.15
25.0 12.0 2.75 13.3 2.95 14.0 3.45 15.7 3.70 17.1 3.95
30.0 11.8 3.35 12.7 3.60 13.5 4.10 15.4 4.27 16.0 4.41
35.0 11.5 4.10 12.1 4.31 12.7 4.43 14.6 4.66 15.0 4.86
40.0 10.9 4.61 11.5 4.66 12.1 4.74 13.7 4.87 14.0 4.95
46.0 10.0 4.50 10.5 4.55 11.0 4.63 12.0 4.71 12.3 4.80
80
-5.0 10.3 1.55 11.4 1.90 12.9 2.15 14.3 2.30 15.5 2.40
0.0 10.3 1.65 11.4 2.00 12.9 2.20 14.3 2.35 15.5 2.45
5.0 10.3 1.80 11.4 2.05 12.9 2.30 14.3 2.40 15.5 2.55
10.0 10.3 1.92 11.4 2.15 12.9 2.40 14.3 2.50 15.5 2.70
15.0 10.3 2.11 11.4 2.30 12.9 2.65 14.3 2.70 15.5 2.90
20.0 10.3 2.31 11.4 2.55 12.9 2.90 14.3 3.00 15.5 3.10
25.0 10.2 2.70 11.3 2.90 12.6 3.19 14.1 3.29 15.3 3.41
30.0 10.0 3.02 11.2 3.33 12.1 3.42 13.8 3.77 14.4 3.86
35.0 9.7 3.38 10.7 3.55 11.3 3.63 13.2 4.20 13.6 4.35
40.0 9.4 3.91 10.2 4.14 10.7 4.29 12.4 4.36 12.7 4.49
46.0 9.2 4.15 9.6 4.22 10.0 4.27 11.1 4.32 11.5 4.40
COOLING CAPACITY
TC : Total Capacity kW.
IP : Input Power kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 13) -
MODEL SELECTION MODEL SELECTION
