6. SYSTEM DESIGN
DIMENSIONS

Unit : mm
570
Min .450
108
100
45
257
201
570
683
390
120
150 to 200
328
398
310
Ceiling opening space
Inspection hatch
(TOP VIEW)
(SIDE VIEW)
(SIDE VIEW)
When installing this kit, an inspection hatch is necessary. (For service and maintenance.) 
