6. SYSTEM DESIGN
SPECIFICATIONS
Model name UTD-GXSA-W UTD-GXSB-W
Power Supply Connecting with Control box of indoor unit
Fixing of Auto Louver Grille crew ing to ange or ectanguar duct
Extension Square Duct Limit 1.0m (Max. duct length between indoor unit and Grille)
Net Dimension
(H x W x D)
mm
(inch)
180x683x(84+9)
[7-3/32x26-7/8x(3-5/16+11/32)]
180x883x(84+9)
[7-3/32x34-3/4x(3-5/16+11/32)]
Weight
Net
kg
(lb.)
2.0 (4.4) 2.5 (5.6)
Gross 3.0 (6.7) 3.5 (7.8)
Color White
Louver Motor Stepping Motor
Material Flame retardant ABS
Accessories Fitting Flame, etc.
Operation
range
Cooling
°C (°F) 18 to 32 (64 to 90)
% RH 80% or less
Heating °C (°F) 16 to 30 (60 to 88)
- (06 - 144) -
