Fujitsu ASYG14KMTA Design & Technical Manual

4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ASYG07KMTA
AFR
m
3
/h
720
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 1.85 0.95 1.83 0.97 1.81 0.98 1.80 1.02 1.78 1.04
-10 -11 2.22 1.00 2.20 1.02 2.17 1.03 2.16 1.07 2.14 1.10
-5 -7 2.59 1.05 2.57 1.07 2.53 1.09 2.52 1.12 2.50 1.15
0 -2 2.96 1.10 2.93 1.13 2.89 1.14 2.88 1.18 2.86 1.21
5 3 3.33 1.15 3.30 1.18 3.26 1.19 3.24 1.23 3.21 1.26
7 6 3.48 1.17 3.45 1.20 3.40 1.21 3.39 1.25 3.36 1.28
10 8 3.70 1.20 3.67 1.23 3.62 1.24 3.60 1.29 3.57 1.32
15 10 3.68 1.11 3.64 1.14 3.59 1.15 3.58 1.19 3.55 1.22
20 15 3.87 1.06 3.84 1.09 3.78 1.10 3.77 1.14 3.74 1.17
24 18 4.03 1.02 3.99 1.05 3.94 1.06 3.92 1.10 3.89 1.12
¢
Model: ASYG09KMTA
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.14 0.99 2.13 1.02 2.12 1.02 2.12 1.06 2.11 1.09
-10 -11 2.57 1.04 2.56 1.07 2.55 1.08 2.55 1.12 2.54 1.15
-5 -7 3.00 1.09 2.99 1.12 2.98 1.13 2.97 1.18 2.96 1.20
0 -2 3.43 1.15 3.42 1.17 3.40 1.19 3.40 1.23 3.39 1.26
5 3 3.86 1.20 3.85 1.23 3.83 1.24 3.83 1.29 3.81 1.32
7 6 4.04 1.22 4.02 1.25 4.00 1.26 4.00 1.31 3.98 1.34
10 8 4.29 1.25 4.28 1.28 4.26 1.29 4.25 1.34 4.24 1.37
15 10 4.43 1.26 4.42 1.29 4.39 1.30 4.39 1.35 4.37 1.38
20 15 4.85 1.27 4.83 1.30 4.80 1.31 4.80 1.36 4.78 1.39
24 18 5.18 1.28 5.16 1.31 5.13 1.32 5.13 1.37 5.11 1.40
¢
Model: ASYG12KMTA
AFR
m
3
/h
770
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.88 1.19 2.86 1.22 2.82 1.23 2.81 1.28 2.78 1.31
-10 -11 3.46 1.25 3.43 1.28 3.38 1.30 3.37 1.35 3.34 1.38
-5 -7 4.04 1.32 4.00 1.35 3.94 1.36 3.93 1.41 3.89 1.44
0 -2 4.62 1.38 4.57 1.41 4.51 1.43 4.49 1.48 4.45 1.51
5 3 5.19 1.44 5.15 1.48 5.07 1.49 5.05 1.55 5.01 1.58
7 6 5.42 1.47 5.38 1.50 5.30 1.52 5.28 1.58 5.23 1.61
10 8 5.77 1.51 5.72 1.54 5.64 1.56 5.62 1.62 5.57 1.65
15 10 5.73 1.40 5.68 1.43 5.60 1.45 5.58 1.50 5.53 1.53
20 15 6.04 1.34 5.98 1.37 5.90 1.38 5.88 1.43 5.82 1.47
24 18 6.28 1.29 6.23 1.32 6.14 1.33 6.12 1.38 6.06 1.41
¢
Model: ASYG14KMTA
AFR
m
3
/h
800
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 3.26 1.36 3.23 1.39 3.19 1.40 3.18 1.45 3.15 1.49
-10 -11 3.92 1.43 3.88 1.46 3.83 1.48 3.81 1.53 3.78 1.57
-5 -7 4.57 1.50 4.53 1.54 4.47 1.55 4.45 1.61 4.41 1.64
0 -2 5.23 1.57 5.18 1.61 5.11 1.63 5.09 1.69 5.04 1.72
5 3 5.88 1.64 5.83 1.68 5.74 1.70 5.72 1.76 5.67 1.80
7 6 6.14 1.67 6.09 1.71 6.00 1.73 5.98 1.79 5.92 1.83
10 8 6.53 1.72 6.48 1.76 6.38 1.77 6.36 1.84 6.30 1.88
15 10 6.49 1.59 6.43 1.63 6.34 1.65 6.32 1.71 6.26 1.75
20 15 6.84 1.52 6.77 1.56 6.68 1.57 6.65 1.63 6.59 1.67
24 18 7.11 1.47 7.05 1.50 6.95 1.52 6.92 1.57 6.86 1.61
- 9 -
WALL MOUNTED ASYG07-14KMTA

Fujitsu ASYG14KMTA Specifications
